Schneider ELAU VIA1002C32F0000 PacDrive iSH100/30044 Intelligent Servo Module
| Place of Origin | Germany |
| Brand Name | Schneider |
| Model Number | VIA1002C32F0000 |
Product Overview
Schneider ELAU VIA1002C32F0000 is a PacDrive iSH100 intelligent servo module used in packaging machinery, motion control systems, production lines, and legacy PacDrive automation equipment. Its core model is iSH100/30044, and the full technical type is iSH100/30044/0/1/00/0/10/11/00.
This model is a strong first-batch upload candidate because it uses a common high-configuration combination: keyed steel shaft, shaft seal, SKM36 multiturn feedback, and holding brake. It covers the iSH100/30044 middle power range while still targeting exact VIA model searches.
Main Features
- PacDrive M iSH100 intelligent servo module
- Commercial reference VIA1002C32F0000
- Core model iSH100/30044
- 0.91kW rated power and 3000 rpm rated speed
- 4.4 Nm standstill torque and 18.3 Nm peak torque
- Keyed steel shaft with shaft seal
- SKM36 multiturn SinCos feedback
- With holding brake
- Integrated SERCOS interface for PacDrive distributed motion systems
Technical Specifications
| Commercial Ref. | VIA1002C32F0000 |
| Core Model | iSH100/30044 |
| Full Technical Model | iSH100/30044/0/1/00/0/10/11/00 |
| Brand | Schneider ELAU |
| Series | PacDrive M iSH100 |
| Product Type | Intelligent Servo Module / Integrated Servo Drive Motor |
| Rated Power | 0.91 kW |
| Rated Speed | 3000 rpm |
| Standstill Torque | 4.4 Nm |
| Rated Torque | 2.9 Nm |
| Peak Torque | 18.3 Nm |
| Shaft Configuration | Keyed steel shaft |
| Protection | Shaft seal IP65 / IP65 housing |
| Encoder | SinCos SKM36 multiturn |
| Holding Brake | Yes |
| Communication | Integrated SERCOS interface |
| Required Power System | PS-5 power supply + DB-5 distribution box |
| Approx. Weight | 7.2 kg |
| Motor Length A | 243 mm |
| Shaft Diameter | 19 mm |
| Key Specification | DIN 6885-A 6x6x30 |
Compatible System and Applications
VIA1002C32F0000 is used in Schneider ELAU PacDrive M distributed servo systems with compatible motion controllers, PS-5 power supply, DB-5 distribution box, machine I/O, HMI panels, and SERCOS communication networks. It is suitable for packaging machines, feeding axes, conveyor systems, labeling machines, cartoning equipment, filling stations, and synchronized production lines.
Maintenance and Replacement Notes
When replacing VIA1002C32F0000, confirm the full VIA reference and not only the iSH100/30044 core model. The replacement should match the keyed shaft, shaft seal, SKM36 multiturn encoder, holding brake, cable set, controller project, and servo parameters. Mismatched feedback or brake configuration may cause axis alarm or commissioning failure.
Related Models
Related iSH100/30044 models include VIA1002C32F0000, VIA1002C31F0000, VIA1002C32A0000, VIA1002C31A0000, VIA1002C22F0000, VIA1002C21F0000, VIA1002C12F0000, VIA1002C11F0000, VIA1002C02F0000, and VIA1002C01F0000. These models may differ by brake, encoder, shaft seal, shaft type, and special suffix configuration.
Inquiry and Supply Notes
DF Automatic supplies Schneider ELAU PacDrive iSH100 intelligent servo modules, iSH070 modules, SM servo motors, PacDrive C200 and C600 controllers, PS-5 power supplies, DB-5 distribution boxes, cables, HMI panels, and industrial automation spare parts for factory maintenance and production line repair.
