Danfoss 084B4082 AK-CC55 Single Coil EEV Case Controller

Product Overview

Danfoss 084B4082 AK-CC55 Single Coil is an electronic case and room controller developed for one-evaporator refrigeration applications using one AKV electronic expansion valve. It provides coordinated refrigeration control for modern commercial display cases and cold-room systems.

Main Features

• Designed for one evaporator and one AKV valve
• S2 injection control functionality
• Pe pressure signal support
• Five relay outputs
• Modbus communication
• Optional LON communication with the correct option
• 115–230 VAC operating supply
• Suitable for CO2-compatible refrigeration applications

Technical Specifications

Compatible System and Applications

The controller is suitable for supermarket cases, refrigerated cabinets, cold rooms and other single-evaporator applications using an AKV valve. Sensors, pressure signals, relay loads and communication accessories must match the installed system.

Maintenance and Replacement Notes

Optional LON communication must not be described as built in unless the correct option is installed. Confirm the controller order number, display requirements, valve type, sensors, wiring and application configuration before replacement.

Related Models

The industrial-pack ordering code is 084B4182. Related products include 084B4081 AK-CC55 Compact, 084B4083 AK-CC55 Single Coil UI and 084B4084 AK-CC55 Multi Coil.

Inquiry and Supply Notes

Please submit the complete controller order number and application information for quotation. Communication options and replacement compatibility should be verified before ordering.
