B&R 7CP474.60-1 System 2003 CPU Controller with RS232 and CAN
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | 7CP474.60-1 |
Product Overview
The B&R 7CP474.60-1 is a CPU controller for the System 2003 automation platform. It provides the processing, memory and communication resources required to control distributed digital and analog I/O in an installed System 2003 machine configuration.
The controller includes SRAM and FlashPROM memory, an RS232 interface, an electrically isolated CAN interface and four positions for compatible screw-in modules. It should be selected according to the original hardware configuration, application program and communication requirements.
Main Features
- CPU controller for B&R System 2003
- 100 kB SRAM application memory
- 512 kB FlashPROM memory
- One RS232 serial communication interface
- One electrically isolated CAN network interface
- Four slots for compatible screw-in modules
- Supports up to 208 digital and 80 analog I/O points, subject to configuration
- 24 VDC supply with specified power consumption of 12.6 W
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | B&R |
| Complete Model | 7CP474.60-1 |
| Product Family | System 2003 |
| SRAM | 100 kB |
| FlashPROM | 512 kB |
| Serial Interface | 1 * RS232 |
| Network Interface | 1 * electrically isolated CAN |
| Expansion | 4 slots for screw-in modules |
| Supply | 24 VDC |
| Power Consumption | 12.6 W |
Compatible System and Applications
- System 2003 machine controllers
- CAN-connected automation devices
- Packaging and production machinery
- Material handling and assembly systems
- Replacement of an existing same-code CPU
Maintenance and Replacement Notes
CPU replacement requires more than matching the System 2003 family name. Confirm the complete model, application software, memory requirements, CAN configuration, RS232 connection, installed screw-in modules and I/O assignment. Program and parameter backups should be prepared before removing the existing controller.
The optional lithium battery and CAN connector should be checked separately. Their presence and condition depend on the installed system configuration.
Related Models
Related components include the 7DM465.7 mixed digital I/O module, 7CM211.7 combination module and 7AF101.7 screw-in-module adapter.
Inquiry and Supply Notes
Please provide the complete CPU nameplate, installed software information, CAN network details, screw-in module list and machine controller configuration when requesting a compatibility review.
