B&R 8AC112.60-1 ACOPOS POWERLINK Communication Interface Module
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | 8AC112.60-1 |
Product Overview
The B&R 8AC112.60-1 is an ACOPOS POWERLINK communication module installed in plug-in slot 1 of a compatible servo drive. It provides real-time network communication for drive control, configuration, diagnostics and synchronization with a B&R automation controller.
The two RJ45 ports form an integrated hub for economical network cabling. The module can operate synchronously with the POWERLINK cycle and is intended for industrial applications requiring coordinated and time-critical motion.
Main Features
- POWERLINK communication interface
- Designed for ACOPOS servo-drive slot 1
- Two RJ45 network ports
- Integrated two-port hub
- 100 Mbit/s transfer rate
- Hardware and software watchdog functionality
- Node address configurable using a switch
- Electrically isolated interface
- Supports star and tree network structures
Technical Specifications
| Complete Model | 8AC112.60-1 |
| Product Type | ACOPOS plug-in communication module |
| Network Interface | POWERLINK |
| Compatible Slot | Slot 1 |
| Port Quantity | 2 * RJ45 |
| Integrated Hub | Yes |
| Transfer Rate | 100 Mbit/s |
| Maximum Segment Length | 100 m |
| Possible Topology | Star or tree |
| Maximum Hub Levels | 10 |
| Electrical Isolation | Yes |
| Maximum Power Consumption | 2.5 W |
| Operating Temperature | 5 to 40°C nominal; 55°C maximum |
Compatible System and Applications
The 8AC112.60-1 is suitable for ACOPOS servo systems used in packaging, printing, textile, plastics-processing, material-handling and coordinated multi-axis machinery.
Maintenance and Replacement Notes
Check the full interface-module model, drive hardware revision, POWERLINK address, controller project and firmware configuration. Do not assume that 8AC112.60-1 and 8AC114.60-2 are automatically interchangeable solely because both use POWERLINK.
Related Models
Related communication modules include 8AC114.60-2 for POWERLINK V2 and 8AC110-series modules for CAN communication. The correct network type and hardware revision must match the existing installation.
Inquiry and Supply Notes
Provide photographs of the drive and interface-module labels, controller model, POWERLINK node setting and Automation Studio project information for cross-checking.
