Rexroth MS2E04-C0BTN-CSSG0-NNNNN-NN MS2E Servo Motor R911398249

Rexroth MS2E04-C0BTN-CSSG0-NNNNN-NN MS2E Synchronous Servo Motor

The MS2E04-C0BTN-CSSG0-NNNNN-NN, requested material reference R911398249, is an MS2E ordering configuration for industrial servo-motor enquiries. This page identifies the full motor designation so overseas maintenance and purchasing teams can request the required spare. Availability, condition, identity and included accessories are confirmed for the actual unit before quotation.

Complete Model and Configuration

The design block C0BTN distinguishes frame length C, low-inertia rotor option 0, winding BT and cooling code N. The CSSG0 option block identifies feedback, connection, shaft and brake selections. Keep the complete NNNNN-NN suffix on enquiries and purchasing records. A shorter family designation cannot establish an exact replacement match.

Feedback and Electrical Connection

This designation uses singleturn absolute feedback and the single-cable connection identified in the configuration table. Confirm the installed drive interface, motor-cable part number, connector pin assignment and parameter requirements against the exact motor and drive documentation. A physically similar connector does not establish feedback compatibility. Cables, mating plugs, adapters and installation accessories are included only when specified in the written supply scope.

Shaft, Brake and Mechanical Comparison

The requested shaft is smooth with a shaft sealing ring. Check shaft diameter and length, flange, centering diameter, coupling arrangement, seal condition and installation clearance against the original motor. This configuration is without a holding brake. An unbraked motor must not be treated as an equivalent replacement for a brake-equipped axis. A holding brake is not presented as a service brake or an independent personnel-protection device.

Confirm the applicable motor data for the full ordering code and operating conditions. Current, torque, speed, voltage and power figures from another frame length or winding must not be transferred to this model. The offered motor must be assessed together with the installed drive, duty cycle and mechanical load before commissioning.

MS2E Application and Nameplate Verification

MS2E is a motor family covered by manufacturer documentation for applications subject to explosion-protection requirements. Suitability of an actual supplied motor depends on its complete designation, original markings, condition, documentation and the installation assessment. This catalog listing and its illustration do not certify an individual motor for a hazardous area.

For such an application, provide the required area classification and the original motor nameplate. Confirm the applicable gas or dust marking, temperature limits, installation requirements and documentation for the actual offered unit with qualified personnel before acceptance. Do not infer an approval or an allowable operating environment from the family name, a generic photograph or another motor's specifications. No certificate number or verified certification status is claimed for the offered unit on this page.

Replacement Enquiry

Please send MS2E04-C0BTN-CSSG0-NNNNN-NN, reference R911398249, quantity, readable nameplate photographs and the installed drive designation. Shaft, flange and connector photographs help establish the configuration. Check both the complete type code and material number on the actual unit. Public directory pairings help identify the enquiry but do not establish the identity, revision or condition of a particular supplied motor. Inspection records, accessories and any warranty terms are agreed in the quotation.

Related MS2E04 Models

These are separate ordering configurations for identification and enquiry comparison. They are not approved substitutes. Compare frame length, winding, feedback, shaft, brake, remaining suffix and applicable original markings before considering an alternative.

Indicative Price and Commercial Terms

The displayed USD 975.00 per piece is an indicative estimate calculated at 65% of a historical eBay displayed price of USD 1500.00 for MS2E04-B0BTN-EMDL0-NNNNS-G1. That reference listing is marked sold and is used only as a historical pricing reference. It is a different configuration: frame length, winding, encoder, connection, shaft, brake and construction or conformity suffixes may differ. The estimate does not establish an exact-model market value, compatibility or actual supply availability. The reference seller's condition, testing, authorization and warranty claims do not apply to this listing. Freight, taxes and import charges are confirmed separately.

Minimum order quantity is 1 piece. Monthly supply target is 10 pieces, subject to actual availability. Confirmed in-stock units are normally dispatched within one week; non-stock sourcing lead time is agreed separately. Payment is by T/T with terms confirmed in the quotation. Protective export packaging and the included supply scope are agreed for the actual motor. No fixed stock, official authorization, guaranteed compatibility or fixed warranty is implied.

Illustrative Images

The images reused from the MS2S catalog are generic motor illustrations at the customer's request. They are not photographs verifying this MS2E model, its connector arrangement, brake, dimensions, nameplate, explosion-protection markings or actual condition. Request photographs of the actual available motor and its complete nameplate before approving an offer.
