Schneider TM262M25MESS8T Modicon M262 8-Axis Sercos Ethernet Motion Controller 3ns
| Place of Origin | Germany |
| Brand Name | Schneider Electric |
| Model Number | TM262M25MESS8T |
Product Overview
The Schneider TM262M25MESS8T is a high-performance Modicon M262 motion controller designed for industrial machines requiring up to eight synchronized motion axes, fast logic processing, Sercos real-time communication and advanced Ethernet connectivity.
The controller provides 3 ns per instruction performance positioning and uses a dual-core controller architecture to manage application execution and communication tasks.
The TM262M25MESS8T is suitable for more demanding synchronized-motion systems than the four-axis TM262M05MESS8T and TM262M15MESS8T references.
Main Features
- Exact commercial reference: TM262M25MESS8T
- Modicon M262 high-performance motion controller
- Up to eight synchronized motion axes
- 3 ns per instruction performance positioning
- Dual-core processor architecture
- Embedded Sercos real-time motion communication
- Embedded Ethernet machine and plant connectivity
- 8T embedded high-speed transistor-I/O configuration
- Encoder-input positioning
- Industrial connectivity and cloud-protocol positioning
- Supports compatible TM3 and TM5 I/O architectures
- Supports compatible smart communication modules
- Programmed with EcoStruxure Machine Expert
Technical Specifications
| Model | TM262M25MESS8T |
| Series | Modicon M262 |
| Controller Family | TM262M |
| Product Type | High-Performance Motion Controller |
| Logic Performance | 3 ns per instruction positioning |
| Maximum Motion Positioning | Up to 8 synchronized axes |
| Processor Architecture | Dual-core application and communication positioning |
| Motion Network | Embedded Sercos real-time communication |
| Ethernet | Embedded Ethernet communication; verify port roles and protocols |
| Power Supply | 24 VDC; verify connector, power range and grounding |
| Embedded I/O Code | 8T |
| Embedded I/O | High-speed transistor I/O; verify exact allocation |
| Encoder Connection | Embedded encoder-interface positioning; verify SSI or incremental configuration |
| I/O Expansion | Compatible Modicon TM3 or TM5 architecture where supported |
| Communication Expansion | Compatible smart communication modules |
| Industrial Protocols | API, TLS, MQTT and OPC UA positioning; verify firmware and project support |
| Programming Software | EcoStruxure Machine Expert |
| Supply Status | Regional availability varies; confirm before quotation |
Compatible System and Applications
The TM262M25MESS8T is suitable for multi-axis packaging equipment, printing and converting lines, robotic machine modules, assembly systems, textile machines and high-speed material-handling equipment.
Its eight-axis positioning is appropriate for machines requiring coordinated master-slave axes, registration, electronic gearing, camming or synchronized conveyor functions.
Actual axis capacity and task-cycle performance depend on the complete application, servo-drive configuration, communication load, safety functions and controller firmware.
Maintenance and Replacement Notes
Confirm that the installed controller is TM262M25MESS8T. TM262M35MESS8T supports a higher axis count, while TM262M15MESS8T has different performance and motion-capacity positioning.
Before replacement, back up the full EcoStruxure Machine Expert project, firmware, libraries, Sercos topology, drive parameters, encoder setup, industrial-protocol configuration, certificates, credentials and expansion-I/O arrangement.
Verify every servo-drive reference, firmware version, motor and feedback type, Sercos address, safety configuration and network-cycle requirement.
After replacement, commission the machine in a controlled sequence and test each axis individually before synchronized automatic operation.
Related Models
TM262M15MESS8T provides four-axis and 5 ns positioning. TM262M35MESS8T provides twenty-four-axis and 3 ns positioning.
TM262L20MESE8T is a high-performance logic controller but does not provide the same Sercos motion-controller architecture.
Inquiry and Supply Notes
Please provide the controller nameplate, hardware revision, firmware, EcoStruxure Machine Expert project, complete Sercos axis list, servo-drive and motor references, encoder configuration, Ethernet protocols, safety architecture and I/O expansion list.
Axis capacity, protocol support, project compatibility, product condition, motion testing, regional availability and delivery time must be confirmed before quotation.
