Danfoss 131F6648 FC-202P18KT4E20H1XGXXXXSXXXXAXBXCXXXXDX 18.5kW 380-480V VFD
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-202P18KT4E20H1XGXXXXSXXXXAXBXCXXXXDX |
Danfoss 131F6648 VLT AQUA Drive FC 202
The Danfoss 131F6648 is an 18.5 kW / 25 HP VLT® AQUA Drive FC 202 variable frequency drive for water, wastewater and pumping applications. It operates from a three-phase 380–480 VAC power supply.
Complete model: FC-202P18KT4E20H1XGXXXXSXXXXAXBXCXXXXDX. This configuration includes an IP20 chassis enclosure, H1 RFI filter and graphical local control panel. An optional fieldbus communication module is not included.
Product Highlights
- 18.5 kW / 25 HP rated power
- Three-phase 380–480 VAC input
- IP20 chassis construction
- H1 RFI filter for EMC Category C1
- Graphical local control panel
- Configuration without optional fieldbus module
- Suitable for cabinet installation
- Designed for water and wastewater applications
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 131F6648 |
| Complete Model | FC-202P18KT4E20H1XGXXXXSXXXXAXBXCXXXXDX |
| Product Series | VLT® AQUA Drive FC 202 |
| Rated Power | 18.5 kW / 25 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H1 / EMC Category C1 |
| Brake Chopper | Not Included |
| Display | Graphical LCP |
| Communication | Not Included |
| PCB Coating | Not Coated |
Typical Applications
Suitable for centrifugal pumps, water-distribution systems, wastewater pumps, circulation pumps, booster stations and water-treatment equipment.
Ordering Notice
Please verify commercial reference 131F6648 and complete model FC-202P18KT4E20H1XGXXXXSXXXXAXBXCXXXXDX. Optional communication hardware should not be assumed to be included.
