Yaskawa CIMR-AU4A0139FAA A1000 Vector VFD 480V 100HP 139A NEMA 1
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | CIMR-AU4A0139FAA |
Product Overview
The Yaskawa CIMR-AU4A0139FAA is a high-power A1000 vector drive designed for three-phase 380–480 VAC industrial systems. Its normal-duty rating is 100 HP and 139 A, while its heavy-duty rating is 75 HP and 112 A. This allows the same drive platform to support high-capacity variable-torque equipment and demanding constant-torque machinery.
Main Features
- 139 A normal-duty output for high-power pumps, fans and process equipment.
- 112 A heavy-duty output for demanding constant-torque applications.
- Normal-duty overload capacity of 120% for 60 seconds.
- Heavy-duty overload capacity of 150% for 60 seconds.
- V/f and current-vector control with optional closed-loop encoder feedback.
- Flexible programmable I/O for sequencing and machine interlocking.
- Standard Modbus RTU and optional industrial network interfaces.
- Supports engineered external braking arrangements for high-inertia loads.
Technical Specifications
| Model | CIMR-AU4A0139FAA |
| Series | A1000 |
| Input Supply | Three-phase 380–480 VAC |
| Normal Duty Rating | 100 HP, 139 A |
| Heavy Duty Rating | 75 HP, 112 A |
| ND Overload Capacity | 120% for 60 seconds |
| HD Overload Capacity | 150% for 60 seconds |
| Feedback Capability | Optional encoder feedback |
| Enclosure | NEMA 1 / IP20 |
Compatible System and Applications
This model is suitable for large pumps, fans, conveyors, mixers, crushers, process lines and other high-power industrial machines. Selection should consider continuous motor current, overload duration, ambient temperature, cabinet ventilation and acceleration requirements. Regenerative or rapid-deceleration applications normally require a correctly rated external braking unit and resistor.
Maintenance and Replacement Notes
For installed-base replacement, verify the complete FAA suffix, physical dimensions, input protection, DC reactor arrangement, communication option and control-terminal functions. Archive the existing parameters before removing the original drive. When considering GA800 migration, check the motor-control mode, I/O mapping, network configuration, cabinet space and external braking circuit.
Related Models
Related A1000 ratings include CIMR-AU4A0103FAA, CIMR-AU4A0165FAA and CIMR-AU4A0208AAA.
Inquiry and Supply Notes
Please provide the full nameplate model, required condition, quantity, application information and destination. Feedback cards, communication boards, keypad and external braking components should be confirmed separately before ordering.
