Schneider ELAU VDM01U50AA00 PacDrive MC-4 Single-Axis Servo Drive
| Place of Origin | Germany |
| Model Number | VDM01U50AA00 / MC-4/11/05/230 (13130246) |
Product Overview
Legacy spare-part inquiry: MC-4/11/05/230 | Reference 13130246 | Commercial identifier VDM01U50AA00. This product page supports genuine ELAU PacDrive M spare-part sourcing for installed machinery. Please match the full technical type, commercial identifier and HW/SW details to your original unit. Condition, completeness, availability and supply scope are confirmed for the actual unit offered.
The ELAU VDM01U50AA00 is a PacDrive M MC-4 single-axis servo drive corresponding to technical model MC-4/11/05/230. Unlike the 400 V MC-4 versions, this model is designed for a 220-240 VAC mains supply and can be connected to a single-phase or three-phase supply according to the installed system design.
The drive provides 5 A rated continuous motor current, 12.5 A peak current for one second and 1.9 kVA rated output power. It integrates the power supply, DC bus, output power stage, braking resistor and servo regulator in one compact unit.
Main Features
- Exact commercial reference: VDM01U50AA00
- Technical model: MC-4/11/05/230
- ELAU order number: 13130246
- Distinct 220-240 VAC MC-4 configuration
- Single-phase or three-phase mains connection
- Rated continuous current: 5 A
- Peak current for 1 second: 12.5 A
- Rated output power: 1.9 kVA
- Integrated Sercos fiber-optic communication
- Integrated 33 ohm braking resistor
- Automatic compatible motor detection
- Encoder and motor feedback processing
- Inverter Enable safety input
- Natural-convection cooling
Technical Specifications
| Model | VDM01U50AA00 |
| Series | PacDrive M MC-4 |
| Technical Model | MC-4/11/05/230 |
| ELAU Order Number | 13130246 |
| Product Type | Single-Axis Servo Drive / Servo Amplifier |
| Rated Continuous Current | 5 A RMS at 8 kHz |
| Peak Current | 12.5 A RMS for 1 second |
| Rated Output Power | 1.9 kVA |
| Mains Supply | Single-phase or three-phase 220-240 VAC, -10% / +10% |
| Supply Frequency | 48-62 Hz |
| Control Supply | 24 VDC; confirm supply-current requirement for the actual hardware version |
| DC Bus Voltage | 260-370 VDC |
| DC Bus Capacitance | 660 uF |
| DC Bus Overvoltage Threshold | 430 VDC |
| Internal Braking Resistor | 33 ohm |
| Continuous Braking Power | 50 W |
| Peak Braking Power | 5 kW |
| Digital Input | 20-30 VDC, approximately 5 mA |
| Inverter Enable Input | 20-30 VDC, approximately 30 mA |
| Input Filter Time | 5 ms |
| Relay Output | 20-30 VDC, maximum 2 A |
| Communication | Sercos fiber-optic input and output |
| Cooling Method | Natural convection |
| Housing Protection | IP20 |
| Operating Temperature | 5-45 deg C without derating; up to 55 deg C with current derating |
| Approximate Packaging Dimensions | 320 x 100 x 400 mm |
| Approximate Net Weight | 3.1 kg |
| Approximate Packaged Weight | 4.0 kg |
| Lifecycle | Discontinued legacy product |
Compatible System and Applications
The VDM01U50AA00 is intended for PacDrive M machines that use a 220-240 VAC supply and require one coordinated servo axis. Typical applications include smaller packaging machines, horizontal and vertical form-fill-seal machines, labeling systems, conveyor axes, printing machinery and compact automated handling equipment.
This 230 V family must not be confused with MC-4 models designed for 380-480 VAC. Confirm the incoming mains system, motor voltage, rated motor current and machine wiring before replacement.
Maintenance and Replacement Notes
Verify the complete commercial reference, MC-4/11/05/230 technical model, firmware suffix, hardware revision and controller project. Confirm whether the installed machine uses a single-phase or three-phase supply and check the protective devices, mains filter, cable cross-section and grounding arrangement.
Back up the machine application and record the Sercos address before removing the original drive. Verify the motor type, electronic nameplate, encoder system, holding brake, motor cable, feedback cable and Inverter Enable circuit.
Do not substitute a 400 V MC-4 drive for this 230 V model. Firmware-suffix variants also require compatibility verification before installation.
Related Models
Confirmed related 5 A references include VDM01U50AH00, VDM01U50AK00, VDM01U50AL00, VDM01U50AP00 and VDM01U50AQ00. These versions share the MC-4/11/05/230 current and voltage platform but represent different firmware families.
Related MC-4 current families include VDM01U30AA00 at 3 A, VDM01D10AA00 at 10 A, VDM01D22AA00 at 22 A and VDM01D50AA00 at 50 A. They are not direct electrical substitutes.
Inquiry and Supply Notes
Please provide the full nameplate, firmware suffix, supply phase, motor model and photographs of all connectors. Confirm whether the drive is required with cables or other PacDrive components. Product condition, test results, firmware, availability and delivery time must be confirmed before quotation.
