Schneider ATV340D11N4 Altivar Machine ATV340 11kW 380–480VAC Sercos III Variable Speed Drive
| Place of Origin | Germany |
| Brand Name | Schneider Electric |
| Model Number | ATV340D11N4 |
Product Overview
The Schneider ATV340D11N4 is an 11 kW, 15 HP high-performance variable speed drive from the Altivar Machine ATV340 series. It is designed for three-phase 380–480 VAC industrial power systems.
The N4 suffix identifies the Sercos-oriented communication version. It supports Sercos III and Modbus serial communication for coordinated machine-control systems.
This drive is intended for high-performance applications requiring fast response, high overload capability and integration into an existing Sercos controller project.
Main Features
- Exact commercial reference: ATV340D11N4
- Rated motor power: 11 kW
- Rated motor power: 15 HP
- Three-phase 380–480 VAC supply
- Sercos-oriented communication version
- Sercos III communication
- Modbus serial communication
- Integrated Safe Torque Off function
- High-performance machine control
- Suitable for rapid acceleration and cyclic loads
Technical Specifications
| Model | ATV340D11N4 |
| Series | Altivar Machine ATV340 |
| Product Type | High-Performance Variable Speed Drive |
| Power Code | D11 |
| Rated Motor Power | 11 kW |
| Rated Motor Power | 15 HP |
| Supply Voltage | Three-phase 380–480 VAC |
| Communication Variant | Sercos-Oriented Version |
| Embedded Communication | Sercos III and Modbus serial |
| Motor Compatibility | Asynchronous and supported synchronous or permanent-magnet motors |
| Feedback Compatibility | Confirm encoder and option configuration |
| Integrated Safety | Safe Torque Off; verify the complete safety circuit |
| Controller Compatibility | Requires confirmation of the Sercos master and machine project |
| Braking Configuration | Verify dynamic-braking and regenerative-energy requirements |
| Installation | Industrial cabinet installation with appropriate cooling |
Compatible System and Applications
The ATV340D11N4 is suitable for Sercos-based conveyors, hoisting systems, packaging machinery, material-handling equipment, textile machinery and coordinated production lines.
The Sercos master, topology, cycle time, project configuration, device addressing and firmware must be checked before replacement.
Maintenance and Replacement Notes
ATV340D11N4 must not automatically be replaced by ATV340D11N4E. Although the power and voltage classes are similar, the communication architectures are different.
Back up the Sercos project, drive parameters, motor data, encoder settings, safety wiring and installed option modules before removing the original drive.
Inspect cooling fans, power terminals, Sercos ports, DC-bus components and stored fault history when evaluating used equipment.
Related Models
ATV340D11N4E is the corresponding 11 kW embedded-Ethernet version.
Adjacent Sercos models include ATV340U75N4 at 7.5 kW and ATV340D15N4 at 15 kW.
Inquiry and Supply Notes
Please provide the original drive model, Sercos controller, motor nameplate, encoder type, braking configuration and machine project information.
Firmware, safety functions, option cards, product condition, test requirements, availability and delivery time must be confirmed before quotation.
