Danfoss VACON NXS00165A5T1SSVA1A2000000 NXS Industrial AC Drive
| Place of Origin | Denmark |
| Brand Name | Vacon |
| Model Number | NXS00165A5T1SSVA1A2000000 |
Product Overview
The Danfoss VACON NXS00165A5T1SSVA1A2000000 is a complete long-reference industrial variable frequency drive from the VACON NXS family. It is based on the NXS00165 current class and is intended for three-phase 380-500 VAC motor-control systems.
The drive is positioned around a 16 A low-overload current rating and approximately 7.5 kW motor power at 400 VAC. For applications requiring higher overload capability, the corresponding heavy-duty motor positioning is approximately 5.5 kW, subject to verification of the motor current and operating cycle.
The complete A5T1SSVA1A2000000 configuration code should be retained during quotation and replacement. Other NXS00165 drives may share the same current rating but differ in enclosure, supply-network compatibility, EMC arrangement, brake chopper, hardware treatment and installed control configuration.
Main Features
- Exact complete reference: NXS00165A5T1SSVA1A2000000
- Base rating reference: NXS00165
- VACON NXS industrial variable frequency drive
- Three-phase 380-500 VAC voltage family
- Approximately 16 A low-overload current rating
- Approximately 7.5 kW low-duty motor positioning at 400 VAC
- Approximately 5.5 kW high-duty motor positioning
- FR5 mechanical frame
- A5 protected-enclosure configuration
- T supply-network or EMC configuration requiring verification
- SSV hardware configuration
- Complete parameter backup required before replacement
Technical Specifications
| Complete Model | NXS00165A5T1SSVA1A2000000 |
| Base Model | NXS00165 |
| Series | VACON NXS |
| Product Type | Industrial Variable Frequency Drive |
| Input Voltage Family | Three-phase 380-500 VAC; confirm original nameplate |
| Low-Overload Current | Approximately 16 A |
| Low-Duty Motor Rating | Approximately 7.5 kW at 400 VAC |
| High-Duty Motor Rating | Approximately 5.5 kW; verify motor current |
| Mechanical Frame | FR5 |
| Enclosure Code | A5; verify exact IP protection and dimensions |
| EMC or Network Code | T; verify incoming supply and grounding requirements |
| Brake Code | 1; confirm brake-chopper and resistor configuration |
| Hardware Code | SSV; verify hardware construction |
| Control Configuration | A1A2000000; verify installed control hardware |
| Supply Status | Regional availability varies; confirm before quotation |
Compatible System and Applications
The NXS00165A5T1SSVA1A2000000 is suitable for pumps, fans, conveyors, mixers, compressors, ventilation equipment and general industrial machinery using compatible three-phase AC motors.
Selection must be based on the motor full-load current, required starting torque, acceleration time, overload cycle, braking demand and installation environment rather than the 7.5 kW rating alone.
The T configuration requires particular attention to the incoming supply network, grounding arrangement, EMC requirements and external filtering. Confirm these conditions against the original installation before replacement.
Maintenance and Replacement Notes
Do not approve a replacement using only the shortened NXS00165 reference. Compare the complete type designation, enclosure, EMC or network configuration, brake chopper, hardware code, control unit and firmware.
Before removing the installed drive, back up the complete parameter set and document the motor data, control mode, acceleration and deceleration times, current limits, analog references, digital inputs, relay outputs and communication settings.
A used or refurbished unit should be tested for cooling-fan operation, DC-link condition, inverter output, keypad function and control-terminal response under a suitable motor load.
Related Models
Search and reference formats for this configuration include NXS00165A5T1SSVA1A2000000 and NXS00165-A5T1SSV-A1A2000000.
Related base ratings include NXS00125, NXS00225 and NXS00315. Other NXS00165 configurations may use different A2 or A5 enclosure codes, H or T network configurations and SSS or SSV hardware codes.
These configurations share the NXS00165 current class but are not automatically interchangeable. The complete original nameplate must be used for compatibility verification.
Inquiry and Supply Notes
Please provide the complete drive nameplate, motor nameplate, incoming voltage, grounding system, application duty, enclosure requirement, braking arrangement, parameter backup and control wiring.
Exact configuration, firmware, product condition, functional testing, regional availability and delivery time must be confirmed before quotation.
