Danfoss VACON NXS00725A2H0SSVA1A2000000 NXS Heavy-Duty AC Drive
| Place of Origin | Denmark |
| Brand Name | Vacon |
| Model Number | NXS00725A2H0SSVA1A2000000 |
Product Overview
The Danfoss VACON NXS00725A2H0SSVA1A2000000 is a complete long-reference industrial variable frequency drive configuration based on the VACON NXS00725 current rating.
The drive is designed for three-phase 380-500 VAC motor-control systems. It provides approximately 72 A low-overload current and is commonly positioned for approximately 37 kW motor operation at 400 VAC.
For higher-overload machinery, the corresponding rating is approximately 61 A and 30 kW. This model uses the FR7 mechanical frame and an A2 enclosure configuration.
Main Features
- Exact complete reference: NXS00725A2H0SSVA1A2000000
- Base technical model: NXS00725
- Three-phase 380-500 VAC voltage class
- 72 A low-overload rated current
- Approximately 79 A at 110 percent overload
- 61 A high-overload rated current
- Approximately 92 A at 150 percent overload
- Approximately 37 kW low-duty motor rating
- Approximately 30 kW high-duty motor rating
- FR7 mechanical frame
- A2 enclosure configuration
- SSV hardware configuration
Technical Specifications
| Complete Model | NXS00725A2H0SSVA1A2000000 |
| Segmented Reference | NXS00725-A2H0SSV-A1A2000000 |
| Base Model | NXS00725 |
| Series | VACON NXS |
| Product Type | Heavy-Duty Industrial Variable Frequency Drive |
| Input Voltage | Three-phase 380-500 VAC |
| Rated Input Current | Approximately 72 A |
| Low-Overload Current | 72 A |
| 110 Percent Overload Current | Approximately 79 A |
| High-Overload Current | 61 A |
| 150 Percent Overload Current | Approximately 92 A |
| Maximum Current | Approximately 122 A |
| Low-Duty Motor Power | Approximately 37 kW at 400 VAC |
| High-Duty Motor Power | Approximately 30 kW |
| Mechanical Frame | FR7 |
| Enclosure Code | A2; verify exact IP protection from the nameplate |
| EMC Code | H |
| Brake Code | 0; verify external braking arrangement |
| Hardware Code | SSV |
| Control Configuration | A1A2000000 |
| Representative Dimensions | Approximately 237 x 591 x 257 mm |
| Representative Net Weight | Approximately 35 kg |
| Supply Status | Regional availability varies; confirm before quotation |
Compatible System and Applications
The NXS00725A2H0SSVA1A2000000 is suitable for pumps, industrial fans, compressors, conveyors, mixers, winches and general production machinery operating within the applicable current and overload range.
Selection must be based on the motor nameplate current and actual load profile. A 37 kW motor with heavy acceleration or repeated torque peaks may need to be evaluated using the lower 30 kW high-duty rating.
The A2 configuration must be compared with the mounting and environmental requirements of the original system.
Maintenance and Replacement Notes
Do not treat NXS00725A2H0SSVA1A2000000 and NXS00725A5H0SSVA1A2000000 as the same product. They share the NXS00725 base rating but use different enclosure configurations.
Before replacement, save the parameter set and document motor data, control mode, acceleration ramps, current limits, digital inputs, analog references, relay outputs and communication settings.
Used or repaired units should be tested for cooling, DC-link stability, inverter output, keypad operation and option-board communication.
Related Models
Market-verified related configuration:
- NXS00725A5H0SSVA1A2000000 - related A5 enclosure configuration
Search formats include NXS00725A2H0SSVA1A2000000 and NXS00725-A2H0SSV-A1A2000000.
Related base ratings include NXS00615 and NXS00875. These models provide different current and power ratings and are not direct substitutes.
Inquiry and Supply Notes
Please provide the complete original type code, enclosure photographs, motor current, supply voltage, operating duty, option-board codes, parameter backup and control wiring.
Exact enclosure compatibility, hardware revision, firmware, product condition, functional testing and delivery time must be confirmed before quotation.
