Danfoss 131B0042 FC-302P7K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX VLT FC 302 7.5kW 16A

Product Overview

The Danfoss 131B0042 is a specific VLT AutomationDrive FC 302 configuration identified by the complete type code FC-302P7K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX.

This product belongs to the FC-302P7K5T5 rating family and is designed for three-phase 380-500 VAC industrial motor applications. The P7K5 code identifies the 7.5 kW or 10 HP power class.

The complete configuration includes an E20 IP20 chassis, H1 RFI-filter configuration, no brake chopper and a graphical local control panel. The part number 131B0042 should be used together with the full type code for exact procurement, repair exchange and replacement verification.

Main Features

• Danfoss part number: 131B0042
• Complete type code: FC-302P7K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX
• Short rating-family reference: FC-302P7K5T5
• VLT AutomationDrive FC 302 series
• 7.5 kW or 10 HP power class
• Three-phase 380-500 VAC mains-voltage class
• 16 A current-class positioning at the lower part of the T5 voltage range
• E20 IP20 chassis enclosure
• H1 RFI Class A1/B filter configuration
• No brake chopper in this configuration
• Graphical local control panel included
• No A, B, C or D expansion option identified

Technical Specifications

Compatible System and Applications

The 131B0042 can be considered for conveyors, compressors, mixers, packaging lines, material-handling systems, lifts, cranes and other industrial machinery using a compatible three-phase motor.

The actual motor current, torque requirement, overload duty, acceleration time, braking demand and ambient installation conditions must be verified before replacement.

This configuration does not include a brake chopper. Applications with rapid stopping, overhauling loads, hoisting or regenerative energy must be reviewed separately and may require a different FC 302 configuration.

Maintenance and Replacement Notes

An exact replacement should match both part number 131B0042 and the complete type code FC-302P7K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX.

The short code FC-302P7K5T5 only identifies the power and voltage family. It does not confirm whether the drive includes a brake chopper, graphical panel, coated PCB, fieldbus card, safety function or expansion option.

Before removing the original unit, back up motor parameters, control mode, speed and torque limits, acceleration and deceleration ramps, digital and analog terminal assignments, communication parameters and machine interlocks.

Related Models

The short rating-family reference is FC-302P7K5T5. Different 7.5 kW FC 302 part numbers may represent versions with or without a brake chopper, different control panels, PCB coating or option boards.

Related exact references include 131B0005 for a 5.5 kW configuration and 131B0037 for a 1.5 kW configuration.

Inquiry and Supply Notes

Please provide the complete nameplate, part number, type code, serial number, motor data, load description, braking requirements, communication network and parameter backup.

Confirm whether the graphical panel must be supplied and whether any fieldbus, safety, encoder or I/O options are installed in the existing machine.

Exact product condition, hardware revision, functional testing, included accessories, warranty, regional availability and delivery time must be confirmed before quotation.
