Danfoss 131B1522 FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX VLT FC302 22kW 380-500V
| Place of Origin | Denmark |
| Brand Name | Vacon |
| Model Number | FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX |
Product Overview
The Danfoss 131B1522 is an exact 22 kW VLT AutomationDrive FC 302 configuration identified by the complete model FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX.
This model is designed for three-phase 380-500 VAC industrial motor-control systems. Its complete code defines an E21 IP21 enclosure, H1 RFI filter, integrated brake chopper, graphical local control panel and standard no-option expansion configuration.
Common procurement searches include 131B1522, FC-302P22KT5, FC302P22KT5, Danfoss FC302 22kW and VLT AutomationDrive 22kW. The exact part number and long model should be shown prominently to capture purchase-ready searches.
Main Features
- Danfoss part number: 131B1522
- Complete type code: FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX
- Short search model: FC-302P22KT5
- VLT AutomationDrive FC 302 product family
- 22 kW or 30 HP power class
- Three-phase 380-500 VAC supply class
- IP21 / Type 1 enclosure
- H1 RFI Class A1/B filter configuration
- Brake chopper included
- Graphical local control panel included
- Standard PCB, mains and adaptation configuration
- No additional expansion option identified
Technical Specifications
| Part Number | 131B1522 |
| Complete Model | FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX |
| Short Search Model | FC-302P22KT5 |
| Series | VLT AutomationDrive FC 302 |
| Product Type | Industrial Frequency Converter |
| Power Class | 22 kW / 30 HP |
| Input Phase | Three-phase |
| Voltage Class | 380-500 VAC |
| Enclosure Code | E21 |
| Protection Positioning | IP21 / Type 1 |
| RFI Filter Code | H1 |
| RFI Positioning | Class A1/B configuration |
| Brake Configuration | Integrated brake chopper |
| Control Panel | Graphical LCP included |
| PCB Configuration | Standard uncoated PCB |
| Mains Option | No additional mains option identified |
| Cable Entry | Standard configuration |
| Software Configuration | Standard software and language package |
| Expansion Cards | No additional A, B, C or D option identified |
| Reference Quality | Exact part number and complete type-code mapping |
| Supply Status | Confirm availability, condition and revision before quotation |
Compatible System and Applications
The 131B1522 is suitable for evaluation in heavy conveyors, compressors, extruders, large mixers, material-handling systems, winding machinery and other 22 kW industrial motor applications.
Final selection must be based on motor current and overload duty rather than nominal power alone. Verify continuous torque, peak torque, acceleration cycle, deceleration energy, operating frequency and ambient temperature.
The included brake chopper does not mean that a braking resistor is supplied. The resistor and associated thermal protection must be selected for the installed machine.
Maintenance and Replacement Notes
Compare both 131B1522 and FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX before approving an exact replacement.
Other FC-302P22KT5 products may be IP20, IP55 or another enclosure and may use different brake, LCP, EMC, coating, safety, fieldbus or I/O configurations.
Save the full parameter file and record motor identification, current limits, torque limits, ramp times, braking data, control-terminal assignments, fieldbus settings and external interlocks.
Related Models
Related exact references include 131B1528 for 18.5 kW, 131B5977 for 30 kW and other complete FC-302P22KT5 configurations with different option characters.
The short model is useful for Google discovery, while the complete type code and part number should control procurement.
Inquiry and Supply Notes
Please provide the original nameplate, motor current, load duty, braking arrangement, communication protocol, encoder or feedback requirements and parameter backup.
Exact hardware revision, condition, included panel, optional cards, testing, warranty, regional availability and delivery time must be confirmed before quotation.
