Danfoss 131B4592 FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX VLT AutomationDrive
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX |
Product Overview
The Danfoss 131B4592 is an exact VLT AutomationDrive FC 302 product reference with the complete type code FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX.
This configuration belongs to the FC-302P37KT5 rating family and is designed for three-phase 380-500 VAC motor-control applications. It combines a 37 kW power class with an E55 IP55 enclosure, H1 RFI-filter configuration, integrated brake chopper and graphical local control panel.
Customers may search using 131B4592, FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX, FC-302P37KT5, FC302 37kW IP55 or Danfoss VLT FC 302 37kW. Exact procurement requires matching the long type code and part number together.
Main Features
- Danfoss part number: 131B4592
- Complete type code: FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX
- Short model: FC-302P37KT5
- VLT AutomationDrive FC 302 family
- 37 kW power class
- Three-phase 380-500 VAC voltage class
- E55 IP55 enclosure configuration
- H1 RFI-filter configuration
- Integrated brake chopper
- Graphical control panel included
- Standard expansion-option configuration
- Suitable for exact procurement and replacement searches
Technical Specifications
| Part Number | 131B4592 |
| Complete Model | FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX |
| Short Search Model | FC-302P37KT5 |
| Product Family | VLT AutomationDrive FC 302 |
| Product Type | High-Performance Industrial AC Drive |
| Power Class | 37 kW |
| Input Phase | Three-phase |
| Voltage Class | 380-500 VAC |
| Enclosure Code | E55 |
| Protection Class | IP55 |
| RFI Filter Code | H1 |
| Brake Configuration | Brake chopper included |
| Local Control Panel | Graphical LCP included |
| Software Configuration | Standard release positioning |
| Expansion Options | AX / BX / CX / DX standard positioning |
| Procurement Confidence | Exact part number plus full type code |
| Supply Status | Confirm exact revision and regional availability |
Compatible System and Applications
The 131B4592 can be evaluated for industrial conveyors, compressors, extruders, mixers, machine tools, winding lines and material-processing equipment.
The motor full-load current, overload requirement, load torque, acceleration cycle, regenerative energy and ambient installation conditions must be reviewed before confirming compatibility.
Applications involving rapid deceleration, high inertia or overhauling loads require correct selection of the external braking resistor and protection devices.
Maintenance and Replacement Notes
Match 131B4592 and FC-302P37KT5E55H1BGXXXXSXXXXAXBXCXXXXDX character by character when an exact replacement is required.
The IP21 version 131B5978 shares the short FC-302P37KT5 model but has a different enclosure. Enclosure characters must not be ignored during procurement.
Back up motor data, control parameters, current and torque limits, acceleration and deceleration ramps, braking settings, terminal functions, fieldbus parameters and machine interlocks.
Related Models
The corresponding 37 kW IP21 reference is 131B5978 with complete type code FC-302P37KT5E21H1BGXXXXSXXXXAXBXCXXXXDX.
Related IP55 references include 131B3265 for 30 kW and 131B3266 for 45 kW.
Inquiry and Supply Notes
Please provide the complete original nameplate, motor nameplate, load profile, braking requirements, communication network, installed option cards and parameter backup.
Exact product condition, hardware revision, testing, included accessories, warranty and delivery time must be confirmed before quotation.
