Danfoss 131B1523 FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX VLT AutomationDrive
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX |
Product Overview
The Danfoss 131B1523 is an exact VLT AutomationDrive FC 302 procurement reference identified by the complete type code FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX.
This product belongs to the FC-302P22KT5 rating family and is designed for three-phase 380-500 VAC industrial motor-control applications. Its complete type code identifies a 22 kW power class, E55 IP55 enclosure, H1 RFI-filter configuration, integrated brake chopper and graphical local control panel.
Purchase-ready customers may search using 131B1523, FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX, FC-302P22KT5, FC302 22kW IP55 or Danfoss VLT FC 302 22kW. The part number and complete type code should both be shown on quotations and replacement checks.
Main Features
- Danfoss part number: 131B1523
- Complete type code: FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX
- Short search model: FC-302P22KT5
- VLT AutomationDrive FC 302 series
- 22 kW power class
- Three-phase 380-500 VAC voltage class
- E55 IP55 enclosure configuration
- H1 RFI-filter configuration
- Integrated brake chopper
- Graphical LCP included
- Standard expansion-option configuration
- Exact procurement-level product reference
Technical Specifications
| Part Number | 131B1523 |
| Complete Model | FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX |
| Short Search Model | FC-302P22KT5 |
| Product Family | VLT AutomationDrive FC 302 |
| Product Type | High-Performance Industrial Drive |
| Power Class | 22 kW |
| Input Phase | Three-phase |
| Mains Voltage | 380-500 VAC |
| Enclosure Code | E55 |
| Protection Class | IP55 |
| RFI Filter | H1 configuration |
| Brake Chopper | Included |
| Control Panel | Graphical LCP included |
| Software Configuration | Standard release positioning |
| Expansion Options | AX / BX / CX / DX standard positioning |
| Procurement Confidence | Exact commercial reference and complete model |
| Supply Status | Confirm revision, condition and regional availability |
Compatible System and Applications
The 131B1523 can be evaluated for conveyors, compressors, mixers, extruders, packaging equipment, winding machinery and industrial process systems.
Final compatibility must be determined using the motor nameplate current, load torque, overload duty, acceleration cycle, braking requirement, switching frequency and environmental conditions.
The IP55 enclosure is suitable for installations requiring a higher protection level than an IP21 drive, but cooling, installation clearance and environmental exposure must still be reviewed.
Maintenance and Replacement Notes
Match both 131B1523 and FC-302P22KT5E55H1BGXXXXSXXXXAXBXCXXXXDX for an exact replacement.
The IP21 reference 131B1522 belongs to the same 22 kW power family but uses an E21 enclosure. The short FC-302P22KT5 reference alone cannot distinguish the two products.
Back up the original drive parameters and document motor data, speed and torque limits, current limits, acceleration and deceleration settings, braking functions, terminal assignments and fieldbus parameters.
Related Models
The corresponding IP21 reference is 131B1522 with complete type code FC-302P22KT5E21H1BGXXXXSXXXXAXBXCXXXXDX.
Related IP55 models include 131B1524 for 18.5 kW and 131B3265 for 30 kW.
Inquiry and Supply Notes
Please provide a clear image of the original drive nameplate, motor data, application duty, braking resistor, communication protocol, installed option cards and parameter backup.
Exact product condition, hardware revision, included graphical panel, functional testing, warranty, packaging and delivery time must be confirmed before quotation.
