Danfoss 131B0958 FC-301P1K5T4E20H2XGCXXXSXXXXAXBXCXXXXDX VLT FC 301

Product Overview

The Danfoss 131B0958 is a specific VLT AutomationDrive FC 301 frequency converter identified by the complete type code FC-301P1K5T4E20H2XGCXXXSXXXXAXBXCXXXXDX.

This FC 301 drive is rated at 1.5 kW and belongs to the T4 three-phase 380-480 VAC voltage class. The E20 enclosure designation identifies an IP20 chassis version intended primarily for installation inside a suitable industrial control cabinet.

The complete type code is important because different FC-301P1K5T4 drives can have different EMC filters, brake hardware, local control panels, PCB protection, communication options and I/O configurations. The short search model FC-301P1K5T4 must not be treated as interchangeable with the complete model.

Main Features

• VLT AutomationDrive FC 301 series frequency converter
• Exact commercial reference 131B0958
• Rated output power of 1.5 kW
• T4 three-phase 380-480 VAC voltage class
• E20 IP20 chassis enclosure for cabinet installation
• Complete configuration retained in the full type code
• Suitable for speed and torque control in industrial machinery
• Supports parameter-based commissioning and motor adaptation

Technical Specifications

Compatible System and Applications

The 131B0958 can be used in FC 301-based machine automation systems requiring a 1.5 kW drive in the 380-480 VAC voltage class. Typical applications include conveyors, packaging machines, material-handling equipment, process machinery, pumps, fans and other variable-speed motor applications.

System suitability depends on the connected motor, load characteristics, control method, required braking performance, communication network and machine control architecture.

Maintenance and Replacement Notes

Before replacing an installed drive, compare the Material Number, complete type code and original nameplate. Confirm the motor data, rated power, output current, voltage class, enclosure, brake chopper, LCP, PCB coating, communication option, I/O option, firmware and hardware revision.

Do not select a replacement only from FC-301P1K5T4. Drives with the same short power model may have different hardware and option configurations. Save or document the original parameter set before removing the existing unit, and verify motor and application parameters before commissioning the replacement.

Related Models

Related FC 301 search models include FC-301P1K1T4, FC-301P1K5T4, FC-301P2K2T4 and other complete FC 301 configurations. Related part number 131B0953 is also associated with a 1.5 kW FC 301 drive but has a different complete type code and must be treated as a separate SKU.

Inquiry and Supply Notes

For an accurate quotation, provide a clear photograph of the original nameplate and confirm the required quantity and condition. Confirm condition, hardware revision and regional availability before quotation.
