Danfoss 131B0996 FC-301P4K0T4E20H2XGCXXXSXXXXAXBXCXXXXDX VLT FC301

Product Overview

The Danfoss 131B0996 is an exact VLT AutomationDrive FC 301 configuration with the complete type code FC-301P4K0T4E20H2XGCXXXSXXXXAXBXCXXXXDX.

This industrial frequency converter is rated at 4 kW and belongs to the T4 three-phase 380-480 VAC voltage class. Its E20 enclosure code identifies an IP20 chassis drive intended for protected installation inside an industrial control cabinet.

The complete model must be retained during procurement because FC-301P4K0T4 is only a short power and voltage designation. It does not identify every installed hardware or option configuration.

Main Features

• VLT AutomationDrive FC 301 machine drive
• Commercial reference 131B0996
• Rated output power of 4 kW
• Three-phase 380-480 VAC voltage class
• E20 IP20 chassis enclosure
• Designed for installation in a protected control cabinet
• Suitable for variable-speed industrial motor control
• Complete configuration identified by the full type code

Technical Specifications

Compatible System and Applications

The 131B0996 is suitable for machinery requiring a 4 kW FC 301 drive in a three-phase 380-480 VAC electrical system. Potential applications include conveyors, mixers, packaging equipment, material-handling machinery, production lines, pumps, fans and general-purpose industrial motor control.

Final application suitability must be checked against the motor nameplate, required output current, overload demand, acceleration and deceleration times, braking requirements and the installed machine control system.

Maintenance and Replacement Notes

Check the Material Number 131B0996 and the entire model FC-301P4K0T4E20H2XGCXXXSXXXXAXBXCXXXXDX against the original nameplate before ordering. Confirm the motor data, rated power, current, enclosure, brake chopper, LCP, PCB coating, communication option, I/O option, firmware and hardware revision.

A parameter backup should be obtained from the existing drive whenever possible. Do not assume that another FC-301P4K0T4 unit can be installed without checking its complete configuration. Commissioning and motor identification procedures must follow the requirements of the installed machine.

Related Models

Related power models include FC-301P3K0T4, FC-301P4K0T4, FC-301P5K5T4 and other FC 301 configurations. Different material numbers or type-code suffixes represent separate hardware configurations and should not be combined into one exact SKU.

Inquiry and Supply Notes

Please provide the original drive nameplate when requesting a replacement or compatible quotation. Confirm condition, hardware revision and regional availability before quotation.
