Danfoss 131L5433 FC-202P5K5T4E20H2XGXXXXSXXXXANBXCXXXXDX VLT AQUA Drive FC 202
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-202P5K5T4E20H2XGXXXXSXXXXANBXCXXXXDX |
Danfoss 131L5433 VLT AQUA Drive FC 202
The Danfoss 131L5433 is a VLT® AQUA Drive FC 202 variable frequency drive designed for water and wastewater applications. It provides a rated power of 5.5 kW / 7.5 HP and operates from a three-phase 380–480 VAC power supply.
Complete model: FC-202P5K5T4E20H2XGXXXXSXXXXANBXCXXXXDX. This exact configuration includes an IP20 chassis enclosure, H2 RFI filter, graphical local control panel and EtherNet/IP communication.
Product Highlights
- Danfoss VLT® AQUA Drive FC 202 series
- 5.5 kW / 7.5 HP rated power
- Three-phase 380–480 VAC input
- IP20 chassis construction
- H2 RFI filter for EMC Category C3
- Graphical local control panel
- EtherNet/IP industrial communication
- Designed for water and wastewater applications
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 131L5433 |
| Complete Model | FC-202P5K5T4E20H2XGXXXXSXXXXANBXCXXXXDX |
| Product Series | VLT® AQUA Drive FC 202 |
| Rated Power | 5.5 kW / 7.5 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H2 / EMC Category C3 |
| Brake Chopper | Not Included |
| Display | Graphical LCP |
| Communication | EtherNet/IP |
| PCB Coating | Not Coated |
Typical Applications
Suitable for water supply pumps, wastewater pumps, pressure booster systems, circulation pumps, treatment systems and other variable-torque water applications.
Ordering Notice
Please confirm both commercial reference 131L5433 and complete model FC-202P5K5T4E20H2XGXXXXSXXXXANBXCXXXXDX before ordering. FC 202 products with the same power rating may have different communication, enclosure, filter and control-panel configurations.
