Danfoss 135N5930 FC-202P18KT4E66H2XGC3SXSXXXXANBXCXXXXDX 18.5kW 380-480V VFD
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-202P18KT4E66H2XGC3SXSXXXXANBXCXXXXDX |
Danfoss 135N5930 VLT AQUA Drive FC 202
The Danfoss 135N5930 is a VLT® AQUA Drive FC 202 variable frequency drive rated at 18.5 kW / 25 HP. It operates from a three-phase 380–480 VAC supply and is designed for water, wastewater and variable-speed pump applications.
Complete model: FC-202P18KT4E66H2XGC3SXSXXXXANBXCXXXXDX. This configuration includes an IP66 / NEMA Type 4X enclosure, H2 RFI filter, graphical local control panel, EtherNet/IP communication and coated circuit boards.
Product Highlights
- 18.5 kW / 25 HP rated power
- Three-phase 380–480 VAC input
- IP66 / NEMA Type 4X enclosure
- H2 RFI filter for EMC Category C3
- Graphical local control panel
- EtherNet/IP industrial communication
- Coated PCB Class 3C3
- Suitable for demanding water and pump environments
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 135N5930 |
| Complete Model | FC-202P18KT4E66H2XGC3SXSXXXXANBXCXXXXDX |
| Product Series | VLT® AQUA Drive FC 202 |
| Rated Power | 18.5 kW / 25 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP66 / NEMA Type 4X |
| RFI Filter | H2 / EMC Category C3 |
| Brake Chopper | Not Included |
| Display | Graphical LCP |
| Communication | EtherNet/IP |
| PCB Coating | Coated PCB Class 3C3 |
Typical Applications
Suitable for water supply pumps, wastewater transfer pumps, booster systems, circulation systems, irrigation equipment and industrial water-treatment installations.
Ordering Notice
Confirm commercial reference 135N5930 and complete model FC-202P18KT4E66H2XGC3SXSXXXXANBXCXXXXDX before ordering. Products with the same power rating may have different enclosure, communication and hardware configurations.
