Danfoss 134F4424 FC-202P55KT4E66H2XGC3XXSXXXXANBXCXXXXDX 55kW 380-480V VFD
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-202P55KT4E66H2XGC3XXSXXXXANBXCXXXXDX |
Danfoss 134F4424 VLT AQUA Drive FC 202
The Danfoss 134F4424 is a high-power VLT® AQUA Drive FC 202 variable frequency drive rated at 55 kW / 75 HP. It is designed for three-phase 380–480 VAC motor systems used in water, wastewater and industrial pump installations.
Complete model: FC-202P55KT4E66H2XGC3XXSXXXXANBXCXXXXDX. This configuration provides an IP66 / NEMA Type 4X enclosure, H2 RFI filter, graphical local control panel, EtherNet/IP communication and coated circuit boards.
Product Highlights
- 55 kW / 75 HP rated power
- Three-phase 380–480 VAC input
- IP66 / NEMA Type 4X enclosed construction
- H2 RFI filter for EMC Category C3
- Graphical local control panel
- EtherNet/IP industrial communication
- Coated PCB Class 3C3
- Suitable for high-capacity pump systems
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 134F4424 |
| Complete Model | FC-202P55KT4E66H2XGC3XXSXXXXANBXCXXXXDX |
| Product Series | VLT® AQUA Drive FC 202 |
| Rated Power | 55 kW / 75 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP66 / NEMA Type 4X |
| RFI Filter | H2 / EMC Category C3 |
| Brake Chopper | Not Included |
| Display | Graphical LCP |
| Communication | EtherNet/IP |
| PCB Coating | Coated PCB Class 3C3 |
Typical Applications
Suitable for large booster pumps, municipal water facilities, wastewater stations, transfer pumps, treatment systems and high-capacity industrial water processes.
Ordering Notice
Confirm commercial reference 134F4424 and complete model FC-202P55KT4E66H2XGC3XXSXXXXANBXCXXXXDX. Installation and commissioning should be carried out by qualified personnel.
