Danfoss 134F0371 FC-202N160T4E20H2XGCXXXSXXXXAXBXCXXXXDX VLT AQUA Drive
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-202N160T4E20H2XGCXXXSXXXXAXBXCXXXXDX |
Danfoss 134F0371 VLT AQUA Drive FC 202
The Danfoss 134F0371 is a high-power VLT® AQUA Drive FC 202 variable frequency drive rated at 160 kW / 250 HP. It is designed for three-phase 380–480 VAC motor systems used in large water, wastewater and industrial pumping installations.
Complete model: FC-202N160T4E20H2XGCXXXSXXXXAXBXCXXXXDX. This configuration includes an IP20 chassis enclosure, H2 RFI filter, graphical local control panel and coated circuit boards. An optional fieldbus communication module is not included.
Product Highlights
- 160 kW / 250 HP rated power
- Three-phase 380–480 VAC input
- IP20 chassis configuration
- H2 RFI filter for EMC Category C3
- Graphical local control panel
- Coated circuit boards
- Configuration without optional fieldbus module
- Suitable for large-capacity water infrastructure
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 134F0371 |
| Complete Model | FC-202N160T4E20H2XGCXXXSXXXXAXBXCXXXXDX |
| Product Series | VLT® AQUA Drive FC 202 |
| Rated Power | 160 kW / 250 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H2 / EMC Category C3 |
| Brake Chopper | Not Included |
| Display | Graphical LCP |
| Communication | Not Included |
| PCB Coating | Coated PCB |
Typical Applications
Suitable for major water-supply installations, large wastewater plants, high-capacity transfer pumps, municipal booster stations and industrial water-treatment facilities.
Installation and Ordering Notice
This is a high-power chassis drive intended for installation within a suitably protected electrical system. Confirm commercial reference 134F0371, complete model FC-202N160T4E20H2XGCXXXSXXXXAXBXCXXXXDX, motor current, cabinet design and cooling requirements before ordering.
