Danfoss 132F0058 FC-051P11KT4E20H3BXCXXXSXXX VLT Micro Drive 11kW 380-480V VFD
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-051P11KT4E20H3BXCXXXSXXX |
Danfoss 132F0058 VLT Micro Drive FC 51
The Danfoss 132F0058 is an 11 kW / 15 HP VLT® Micro Drive FC 51 variable frequency drive for three-phase 380–480 VAC industrial motor systems.
Complete model: FC-051P11KT4E20H3BXCXXXSXXX. This configuration combines an IP20 chassis enclosure, H3 RFI filter, integrated brake chopper, coated PCB and RS-485 communication. It is supplied without an LCP control panel.
Product Highlights
- 11 kW / 15 HP rated power
- Three-phase 380–480 VAC input
- IP20 chassis configuration
- H3 RFI Class A1/B filter
- Integrated brake chopper
- RS-485 and Modbus RTU communication
- Coated circuit boards
- Compact solution for industrial motor control
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 132F0058 |
| Complete Model | FC-051P11KT4E20H3BXCXXXSXXX |
| Product Series | VLT® Micro Drive FC 51 |
| Rated Power | 11 kW / 15 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H3 / RFI Class A1/B |
| Brake Chopper | Integrated |
| Display | Supplied Without LCP |
| Communication | RS-485 / Modbus RTU |
| PCB Coating | Coated PCB |
Typical Applications
Suitable for pumps, ventilation equipment, conveyors, mixers, process machinery and general industrial automation systems.
Lifecycle and Replacement Notice
This FC 51 drive is a legacy product and is no longer in regular production. Limited replacement, surplus or repair stock may remain available. The Danfoss iC2-Micro is the official successor series; however, the replacement must be selected by exact sales code or type code.
Ordering Notice
Verify commercial reference 132F0058 and complete model FC-051P11KT4E20H3BXCXXXSXXX. Confirm motor current, dimensions, terminal arrangement, braking requirements and LCP requirements.
