Danfoss 132F0022 FC-051P2K2T4E20H3BXCXXXSXXX VLT Micro Drive 2.2kW 380-480V VFD
| Place of Origin | Denmark |
| Brand Name | Danfoss |
| Model Number | FC-051P2K2T4E20H3BXCXXXSXXX |
Danfoss 132F0022 VLT Micro Drive FC 51
The Danfoss 132F0022 is a compact VLT® Micro Drive FC 51 variable frequency drive rated at 2.2 kW / 3 HP. It operates from a three-phase 380–480 VAC power supply.
Complete model: FC-051P2K2T4E20H3BXCXXXSXXX. This exact configuration includes an IP20 chassis enclosure, H3 RFI filter, integrated brake chopper, coated PCB and built-in RS-485 communication. It is supplied without an LCP.
Product Highlights
- 2.2 kW / 3 HP rated power
- Three-phase 380–480 VAC input
- Compact IP20 chassis design
- H3 RFI Class A1/B filter
- Integrated brake chopper
- RS-485 communication with Modbus RTU
- Coated circuit boards
- Suitable for compact machinery and OEM equipment
Technical Specifications
| Brand | Danfoss |
| Commercial Reference | 132F0022 |
| Complete Model | FC-051P2K2T4E20H3BXCXXXSXXX |
| Product Series | VLT® Micro Drive FC 51 |
| Rated Power | 2.2 kW / 3 HP |
| Input Voltage | 3-Phase 380–480 VAC |
| Enclosure | IP20 / Chassis |
| RFI Filter | H3 / RFI Class A1/B |
| Brake Chopper | Integrated |
| Display | Supplied Without LCP |
| Communication | RS-485 / Modbus RTU |
| PCB Coating | Coated PCB |
Typical Applications
Suitable for small pumps, fans, conveyors, packaging machinery, food-processing equipment and compact industrial machines.
Lifecycle and Replacement Notice
The FC 51 series is no longer in regular production. This product is primarily relevant to maintenance, spare-part and legacy-equipment replacement requirements. Use the exact type code when selecting a Danfoss iC2-Micro successor.
Ordering Notice
Confirm commercial reference 132F0022 and complete model FC-051P2K2T4E20H3BXCXXXSXXX. The LCP and external brake resistor are not automatically included.
