Danfoss 132F0060 FC-051P18KT4E20H3BXCXXXSXXX VLT Micro Drive 18.5kW 380-480V VFD

Danfoss 132F0060 VLT Micro Drive FC 51

The Danfoss 132F0060 is a high-power model within the VLT® Micro Drive FC 51 series. It is rated at 18.5 kW / 25 HP for three-phase 380–480 VAC industrial motor systems.

Complete model: FC-051P18KT4E20H3BXCXXXSXXX. This configuration includes an IP20 chassis enclosure, H3 RFI filter, integrated brake chopper, coated circuit boards and built-in RS-485 communication. An LCP control panel is not included.

Product Highlights

• 18.5 kW / 25 HP rated power
• Three-phase 380–480 VAC input
• IP20 chassis construction
• H3 RFI Class A1/B filter
• Integrated brake chopper
• RS-485 communication with Modbus RTU support
• Coated PCB
• High-value FC 51 legacy replacement model

Technical Specifications

Typical Applications

Suitable for larger pumps, fans, conveyors, mixers, process equipment, material-handling systems and industrial machinery.

Lifecycle and Replacement Notice

The FC 51 series is no longer in regular production. Availability may depend on remaining distributor, surplus, repaired or replacement stock. Danfoss identifies iC2-Micro as the successor series, but the correct replacement must be selected using the exact sales code or type code.

Installation and Ordering Notice

Confirm commercial reference 132F0060 and complete model FC-051P18KT4E20H3BXCXXXSXXX. Because this is a higher-power chassis drive, verify cabinet protection, cooling, motor current, braking requirements and installation dimensions before purchasing.
