Yaskawa CIPR-GA70C4007BBAA-BAAAAA GA700 Vector VFD 400V 3kW 7.1A
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | CIPR-GA70C4007BBAA-BAAAAA |
Product Overview
The Yaskawa CIPR-GA70C4007BBAA-BAAAAA is a European-configuration GA700 industrial AC drive designed for three-phase 380-480 VAC motor systems. It provides a 3 kW and 7.1 A Normal Duty rating or a 2.2 kW and 5.5 A Heavy Duty rating. The integrated EMC filter differentiates this C-version drive from standard regional configurations without an internal filter and supports installation in industrial environments requiring improved conducted-emission control.
Main Features
- Dual Normal Duty and Heavy Duty ratings for application-specific sizing.
- V/f, sensorless vector and supported closed-loop vector control methods.
- Compatible with induction, permanent-magnet and synchronous reluctance motors.
- 110% Normal Duty overload or 150% Heavy Duty overload for 60 seconds.
- Integrated C3 EMC filter for industrial electrical installations.
- Built-in braking transistor for compatible dynamic-braking applications.
- Dual-channel Safe Torque Off with SIL3 and PL e capability.
- Removable LCD keypad for setup, monitoring and parameter transfer.
Technical Specifications
| Complete Model | CIPR-GA70C4007BBAA-BAAAAA |
| Standard Model | CIPR-GA70C4007BBA |
| Input Supply | Three-phase 380-480 VAC, 50/60 Hz |
| Normal Duty Rating | 3 kW, 7.1 A |
| Heavy Duty Rating | 2.2 kW, 5.5 A |
| Overload Capacity | 110% ND / 150% HD for 60 seconds |
| EMC Configuration | Integrated C3 EMC filter |
| Enclosure | IP20 |
| Maximum Output Frequency | Up to 590 Hz, subject to motor and setup limitations |
Compatible System and Applications
This model is suitable for pumps, fans, conveyors, packaging machines, compact process equipment and general industrial automation. Normal Duty should be considered for variable-torque loads, while Heavy Duty should be selected where higher starting torque or repeated acceleration is required.
Maintenance and Replacement Notes
Confirm the complete order code, input voltage, motor current, EMC configuration and installed option cards before replacement. Back up the original parameters and verify the control-terminal assignment. When dynamic braking is required, select the external braking resistor according to resistance, braking torque, duty cycle and thermal capacity.
Related Models
Related models include CIPR-GA70C4012BBAA-BAAAAA, CIPR-GA70C4018BBAA-BAAAAA and CIPR-GA70C4023BBAA-BAAAAA.
Inquiry and Supply Notes
Please provide the original nameplate, motor specifications, application load and communication requirements for quotation and compatibility confirmation.
