Yaskawa CIPR-GA70C4018BBAA-BAAAAA GA700 Vector VFD 400V 7.5kW 17.5A

Product Overview

The Yaskawa CIPR-GA70C4018BBAA-BAAAAA is a 400 V class GA700 AC drive with an integrated industrial EMC filter. It provides a 7.5 kW and 17.5 A Normal Duty rating or a 5.5 kW and 14.8 A Heavy Duty rating. Its advanced control architecture supports precise operation of induction, permanent-magnet and synchronous reluctance motors in both general automation and demanding constant-torque applications.

Main Features

• V/f, sensorless vector and optional encoder-feedback vector control.
• 17.5 A Normal Duty output with 110% overload for 60 seconds.
• 14.8 A Heavy Duty output with 150% overload for 60 seconds.
• Integrated Category C3 EMC filter for industrial environments.
• Built-in braking transistor for compatible resistor braking systems.
• Dual-channel Safe Torque Off rated up to SIL3 and PL e.
• Three analog inputs, eight digital inputs and expandable control options.
• Removable keypad supports parameter copying and fault diagnostics.

Technical Specifications

Compatible System and Applications

Suitable applications include process pumps, industrial fans, conveyors, mixers, compressors, packaging machines and material-handling equipment. For applications with frequent starts, rapid deceleration or high low-speed torque, the 14.8 A Heavy Duty rating should be used for drive selection.

Maintenance and Replacement Notes

Confirm the complete CIPR order code, firmware level, EMC configuration, control wiring and option cards. The drive should be mounted inside a suitable enclosure with adequate ventilation. A braking resistor is not included and must be selected separately when regenerative energy cannot be absorbed by the motor and load.

Related Models

Related models include CIPR-GA70C4012BBAA-BAAAAA, CIPR-GA70C4023BBAA-BAAAAA and CIPR-GA70C4031BBAA-BAAAAA.

Inquiry and Supply Notes

Please submit the nameplate model, motor data and application information before confirming replacement compatibility.
