IAI RCS-C-SS-I-60-2 60W AC Servo Actuator Controller

Product Overview

IAI RCS-C-SS-I-60-2 is a single-axis AC servo actuator controller designed for a matching IAI RCS-SS electric actuator. The model configuration specifies an SS actuator type, incremental feedback, a 60 W motor capacity and a 200 VAC controller power input.

The controller manages actuator positioning, speed, acceleration, deceleration, home return and operating status according to stored parameters and commands from the machine PLC. It is primarily used for maintenance of existing automation equipment requiring the original RCS-C configuration.

Main Features

• Single-axis control for a matching IAI RCS-SS actuator
• Designed for a 60 W AC servo motor configuration
• Incremental encoder and feedback specification
• 200 VAC controller input configuration
• NPN sink-type parallel I/O
• Supports stored position control and PLC command operation
• Suitable for legacy production-equipment maintenance

Technical Specifications

Related Models

Related IAI family model: RCS-C-SA5-A-20-0. This related controller belongs to the RCS-C family but uses an SA5 actuator configuration, absolute feedback, a 20 W motor rating and a different power-supply code.

RCS-C-SA5-A-20-0 is included for related-model coverage only and is not automatically interchangeable with RCS-C-SS-I-60-2. Confirm the actuator type, encoder system, motor capacity, input voltage, I/O configuration, firmware, connectors and stored parameters before replacement.

Compatible Systems and Applications

RCS-C-SS-I-60-2 can be used in automated assembly equipment, transfer systems, inspection machines, production fixtures, loading stations and packaging machinery fitted with a compatible RCS-SS actuator.

The controller can receive position selection, start, reset and other operating commands through parallel I/O while returning completion, operating and alarm status signals. The connected actuator and controller must remain matched as one configured system.

Maintenance and Replacement Notes

Back up all available controller parameters and position data before removing the original unit. Record the actuator direction, home position, travel limits, speed settings, acceleration values and PLC input and output assignments.

The final code 2 identifies a 200 VAC controller configuration. Do not substitute a 24 VDC, 100 VAC or differently rated controller without completing an electrical and actuator-compatibility review.

IAI identifies RCS-C as a legacy controller family. For 100 VAC and 200 VAC applications, the stated successor direction is SCON-CB, but conversion is not necessarily a direct drop-in replacement and may require changes to wiring, connectors, dimensions, parameters or the connected actuator system.

Inquiry and Supply Notes

Please provide photographs of the RCS-C-SS-I-60-2 controller label, connected actuator nameplate and terminal wiring when requesting a quotation. Product condition, included connectors, parameter service, firmware, warranty and delivery time should be confirmed before purchase.
