YUKEN DSG-01-3C4-A120-N-7090 AC120V Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-01-3C4-A120-N-7090 |
Product Details
Brand:
YUKEN
Model:
DSG-01-3C4-A120-N-7090
Series:
DSG-01
Spool Function:
3C4 / Unloading Center
Valve Configuration:
4-Way, 3-Position
Coil Voltage:
AC 120V
Electrical Option:
Indicator Connector
Nominal Size:
NG06 / CETOP 03
Maximum Pressure:
Up To 31.5 MPa
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 93.77 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DSG-01-3C4-A120-N-7090 AC120V Directional Valve
The YUKEN DSG-01-3C4-A120-N-7090 is an AC120V solenoid-operated directional valve with a 3C4 unloading-center spool function.
This model combines a four-way, three-position hydraulic configuration, an indicator connector option and an NG06 / CETOP 03 mounting pattern.
Main Features
- AC120V solenoid operation
- Indicator connector option
- Four-way, three-position configuration
- 3C4 unloading-center spool function
- Operating pressure up to 31.5 MPa
- NG06 / CETOP 03 subplate mounting
Technical Specifications
| Brand | YUKEN |
| Model | DSG-01-3C4-A120-N-7090 |
| Series | DSG-01 |
| Spool Function | 3C4 / Unloading Center |
| Configuration | 4-Way, 3-Position |
| Coil Voltage | AC 120V |
| Electrical Option | Indicator Connector |
| Nominal Size | NG06 / CETOP 03 |
| Maximum Pressure | Up to 31.5 MPa |
| Design Number | 7090 |
Typical Applications
- Hydraulic power systems
- Industrial machinery
- Machine tools
- Hydraulic presses
- Automated production equipment
Selection Notes
Verify the AC120V coil, indicator connector, 3C4 center function and 7090 design suffix. Do not substitute a valve with a different spool code without checking the circuit.
