YUKEN DSG-03-3C4-D24-N-50 DC24V Solenoid Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-03-3C4-D24-N-5090 |
Product Details
Brand:
YUKEN
Model:
DSG-03-3C4-D24-N-5090
Series:
DSG-03
Spool Function:
3C4 / Unloading Center
Valve Configuration:
4-Way, 3-Position
Coil Voltage:
DC 24V
Electrical Option:
Electrical Option
Nominal Size:
NG10 / CETOP 05
Maximum Pressure:
Up To 31.5 MPa
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 163.80 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DSG-03-3C4-D24-N-50 DC24V Solenoid Directional Valve
The YUKEN DSG-03-3C4-D24-N-50 is a DC24V solenoid-operated directional valve with a 3C4 unloading-center spool function.
It features a four-way, three-position configuration, an N electrical connector option and an NG10 / CETOP 05 mounting interface.
Main Features
- DC24V solenoid operation
- N indicator connector option
- Four-way, three-position configuration
- 3C4 unloading-center spool function
- Pressure rating up to 31.5 MPa
- NG10 / CETOP 05 subplate mounting
Technical Specifications
| Brand | YUKEN |
| Model | DSG-03-3C4-D24-N-50 |
| Valve Type | Solenoid Operated Directional Valve |
| Series | DSG-03 |
| Spool Function | 3C4 / Unloading Center |
| Configuration | 4-Way, 3-Position |
| Coil Voltage | DC 24V |
| Electrical Option | N Indicator Connector |
| Nominal Size | NG10 / CETOP 05 |
| Maximum Pressure | Up to 31.5 MPa |
| Design Number | 50 |
Typical Applications
- Hydraulic unloading circuits
- Industrial power units
- Machine tools
- Hydraulic presses
- Automated production equipment
Selection Notes
The 3C4 center-position flow path differs from 3C2, 3C10 and 3C60 configurations. Verify the circuit, DC24V supply, N connector and complete 5090 suffix before replacement.
Stock status, product condition and delivery time are confirmed separately.
