YUKEN DCG-01-2B2-Y-4011 DC24V Hydraulic Directional Control Valve
|
YUKEN DCG-01-2B2-Y-4011 DC24V Hydraulic Directional Control Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DCG-01-2B2-Y-4011 |
Product Details
Valve Type:
Hydraulic Directional Control Valve
Series:
DCG-01
Spool Function:
2B2
Valve Configuration:
4-Way, 2-Position
Control Voltage:
DC 24V
Maximum Pressure:
Up To 21 MPa
Nominal Size:
Size 01
Design Number:
4011
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 145.20 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DCG-01-2B2-Y-4011 DC24V Hydraulic Directional Control Valve
The YUKEN DCG-01-2B2-Y-4011 is a hydraulic directional control valve with a two-position 2B2 spool configuration.
It is intended for controlling actuator direction in industrial hydraulic machinery and has a listed maximum pressure of 21 MPa.
Main Features
- Four-way, two-position directional function
- YUKEN 2B2 spool configuration
- DC24V control specification
- Pressure capability up to 21 MPa
- Compact size 01 construction
Technical Specifications
| Brand | YUKEN |
| Model | DCG-01-2B2-Y-4011 |
| Valve Type | Hydraulic Directional Control Valve |
| Series | DCG-01 |
| Spool Function | 2B2 |
| Configuration | 4-Way, 2-Position |
| Control Voltage | DC 24V |
| Maximum Pressure | Up to 21 MPa |
| Design Number | 4011 |
Typical Applications
- Hydraulic power units
- Machine tools
- Industrial automation machinery
- Hydraulic clamping equipment
- Material-handling systems
Selection Notes
Verify the actual control voltage, 2B2 spool function, Y option, connector, mounting interface and complete 4011 suffix against the valve nameplate.
