Gefran 1000-R0-1R-0-1 1/8 DIN PID Controller F000010

Product Overview

The Gefran 1000-R0-1R-0-1, ordering code F000010, is a configurable 1/8 DIN PID controller for industrial temperature and process-control applications. This configuration combines a universal main input, relay/logic control output and one alarm with a 100–240 VAC/DC supply. Typical uses include heaters, ovens, packaging machines, laboratory equipment and general process panels.

Main Features

• Universal input for supported thermocouples, Pt100 and linear process signals.
• Relay and logic main-control output arrangement.
• One configurable alarm in this exact configuration.
• Self-tuning, autotuning, soft-start and manual/automatic transfer functions at series level.
• Front-panel parameter configuration and dual LED display.
• Auxiliary current-transformer input supported by the 1000 platform.

Technical Specifications

Compatible System and Applications

The unit can accept supported thermocouple, resistance-temperature and linear process inputs after correct configuration and wiring. The installed input type, scale, control action and output circuit must be confirmed before energizing the controller. External shunts or signal-conditioning components may be required for certain current or voltage inputs.

Maintenance and Replacement Notes

Record the input selection, PID settings, alarm threshold, output action and terminal wiring before removal. Confirm that the replacement carries both F000010 and model 1000-R0-1R-0-1. Additional suffixes such as M55 or A06 can represent application-specific variants and must not be silently substituted for the base configuration.

Related Models

The 1001 and 1101 belong to the same controller family but use different hardware formats and display arrangements. Other 1000 configurations may provide additional alarms, analog control output or serial communication. Modern Gefran 1200, 1250 and 1350 controllers belong to different generations and require separate dimensional, wiring and functional review. Related models are provided for family reference only and are not automatically interchangeable.

Inquiry and Supply Notes

Provide the complete controller nameplate, F000010, input sensor type, output-load details and required condition when requesting a quotation. The suggested price is an upload reference calculated from limited qualifying new-unit quotations; used and open-box listings were excluded, and no current inventory or delivery commitment is implied.
