Gefran 1200-RR00-00-0-1 PID Temperature Controller F023210

Product Overview

The Gefran 1200-RR00-00-0-1, ordering code F023210, is a 1/8 DIN microprocessor-based PID controller for temperature regulation and general industrial process control. The exact configuration uses two relay outputs and a 100–240 VAC supply. It is suitable for control panels used with ovens, heaters, packaging machinery, plastics equipment and other processes requiring stable single-loop regulation.

Main Features

• PID control with self-tuning and autotuning functions supported by the 1200 platform.
• Universal process input for compatible thermocouple, RTD and linear signals.
• Two relay outputs associated with the RR00 configuration.
• Double four-digit LED display for process value and setpoint indication.
• Four-key front operator interface with configurable status indicators.
• IP65 front-panel protection under the specified installation conditions.

Technical Specifications

Compatible System and Applications

The controller can be used with supported thermocouple, resistance-temperature and linear process signals after correct input configuration. Sensor type, scale, control action, relay contact loading and heating or cooling logic must match the installed machine. External protective devices must be selected for the connected load.

Maintenance and Replacement Notes

Record the input selection, PID values, alarm settings and relay functions before removing the existing controller. Isolate the supply and verify terminal wiring before installation. Confirm both F023210 and 1200-RR00-00-0-1 because similar 1200 models may have logic, analog, communication or auxiliary-input options.

Related Models

1200-RR00-02-0-1 has a different option position and must be treated as a separate configuration. The 600 series uses a smaller 1/16 DIN format, while the 1300 series uses a larger 1/4 DIN format. The later 1250 family has a different interface and hardware generation. Related models are provided for family reference only and are not automatically interchangeable.

Inquiry and Supply Notes

Please provide the complete nameplate, F023210, input type, control-output requirement and required quantity with the inquiry. The suggested price is based on the median of qualifying exact-model new listings multiplied by 70 percent. It is an upload reference and does not confirm current inventory or delivery time.
