Gefran 600-R-R-0-0-1 Compact PID Temperature Controller F000052

Product Overview

The Gefran 600-R-R-0-0-1, ordering code F000052, is a compact 1/16 DIN PID temperature and process controller. This configuration provides two relay outputs and a 100–240 VAC supply without an installed serial-communication option. It is intended for control cabinets where limited panel space and straightforward closed-loop regulation are important.

Main Features

• Compact 48 * 48 mm panel-mounted controller.
• Universal input configurable for supported temperature and linear process signals.
• Two relay outputs for control or configurable alarm functions.
• PID control with automatic and manual tuning functions supported by the series.
• Dual four-digit LED display and four-key front interface.
• IP65 front protection when correctly installed.

Technical Specifications

Compatible System and Applications

Typical uses include ovens, sealing machinery, packaging equipment, laboratory heating systems and plastics-processing machinery. The sensor signal, input scale, heating or cooling action and relay-contact load must be verified for the actual application. Power loads should normally be switched through correctly rated contactors or solid-state devices where required.

Maintenance and Replacement Notes

Save the installed parameters and label all wires before replacement. Confirm the control direction, alarm allocation and load-switching circuit. The two available outputs may be assigned differently by the machine builder; therefore physical output count alone does not establish functional compatibility.

Related Models

600-R-D-0-0-1 uses relay and logic output types instead of two relay outputs. Versions such as 600-R-D-C-0-1 add different communication or option codes, while 600 OF is an open-frame product for embedded installations. The 1200 uses a wider 1/8 DIN panel format. Related models are provided for family reference only and are not automatically interchangeable.

Inquiry and Supply Notes

Specify F000052 and the complete 600-R-R-0-0-1 model when requesting a quotation. Only three qualifying exact-model new price samples were available, so the suggested price should be treated as a limited-sample upload reference rather than a precise market valuation.
