Gefran 600-R-D-0-0-1 Relay Logic PID Controller F000059
| Place of Origin | USA |
| Brand Name | Gefran |
| Model Number | 600-R-D-0-0-1 |
Product Overview
The Gefran 600-R-D-0-0-1, ordering code F000059, is a 1/16 DIN PID controller configured with relay and logic control outputs. It is designed for temperature and process-control panels requiring a compact controller that can operate a relay circuit and provide a logic signal for a compatible external solid-state switching device.
Main Features
- Universal configurable input for supported process and temperature signals.
- Relay and logic output arrangement identified by the R-D configuration.
- Compact 48 * 48 mm front-panel format.
- PID regulation with tuning, soft-start and alarm functions supported by the 600 platform.
- Dual LED displays for process value and setpoint.
- 100–240 VAC power-supply configuration.
Technical Specifications
| Manufacturer | Gefran |
| Complete Model | 600-R-D-0-0-1 |
| Ordering Code | F000059 |
| Product Type | PID Temperature and Process Controller |
| Panel Format | 48 * 48 mm, 1/16 DIN |
| Output Types | Relay and Logic |
| Communication | Not Included in This Configuration |
| Power Supply | 100–240 VAC |
Compatible System and Applications
The logic output must be connected only to a compatible external input circuit, such as a correctly specified solid-state relay. It must not be treated as a mains-load output. The relay output contact rating, logic signal requirement, input sensor and control action must all be checked against the machine wiring diagram.
Maintenance and Replacement Notes
Do not replace this configuration with 600-R-R-0-0-1 without reviewing the controlled equipment. The second output changes from logic to relay between these models, creating a material wiring and load-interface difference. Record the parameters, disconnect the supply and verify every terminal before commissioning.
Related Models
600-R-R-0-0-1, ordering code F000052, provides two relay outputs. Other 600 configurations may add serial communication, a current-transformer input or additional output functions. The 1200 series offers a 1/8 DIN format, while the 650 belongs to a later controller platform with an LCD operator interface. Related models are provided for family reference only and are not automatically interchangeable.
Inquiry and Supply Notes
Provide F000059, model 600-R-D-0-0-1, the existing terminal label and details of the external solid-state switching circuit. Only one qualifying exact-model new listing was available for pricing. USD 272/Unit is therefore a provisional upload price, not a precise market median or statement of availability.
