Gefran PY-2-C-025 0000X000X00 25 mm Position Transducer

Product Overview

The Gefran PY-2-C-025 0000X000X00 is a PY2-series spring-return potentiometric position transducer with a verified 25 mm electrical stroke. Gefran ordering number F004199 identifies this standard connector configuration. The sensor measures movement through direct contact between its stainless-steel ball tip and the monitored machine component.

The internal return spring maintains probe contact as the target moves. This makes the unit suitable for short-travel inspection fixtures, dimensional monitoring, machine slides, clamping mechanisms and other applications where installing a separate linkage would be impractical.

Model-Specific Features

• Verified Gefran ordering number F004199.
• 25 mm useful electrical stroke.
• Spring-return control rod with double support.
• M2.5 threaded stainless-steel ball tip.
• C electrical configuration with 5-pole DIN 43322 connector.
• Absolute potentiometric output requiring no homing sequence.

Technical Specifications

Installation and Contact Geometry

Install the body so that the target moves along the control-rod axis. The probe should have sufficient preload to maintain contact but must not be compressed beyond its mechanical limit. Side loading, impact, surface discontinuities or an incorrectly positioned target can accelerate wear and cause unstable measurements.

Connector and Wiring Verification

The C version must be matched with the correct 5-pole connector and terminal arrangement. Confirm excitation, signal and common conductors using the Gefran wiring information and the machine schematic. Published voltage limits must not be interpreted as the machine’s required operating voltage.

Related Models and Differences

PY-2-C-010 0000X000X00 F004190 has a shorter 10 mm stroke. PY-2-C-050 0000X000X00 F004207 provides 50 mm travel. PY-2-F-025-S01M 0000X000X00 F004228 has the same nominal stroke but uses a 1 m screened cable instead of the DIN connector.

Related models are provided for family reference only and are not automatically interchangeable.

Maintenance and Replacement Notes

Inspect the return action, ball tip, control rod and connector for wear or contamination. Before ordering, verify F004199, the complete 0000X000X00 configuration, 25 mm stroke and C connection. Additional suffixes such as L000X000X00 or 0000X000E00 indicate different configurations and must not be merged with this product.

Inquiry and Supply Notes

Provide photographs of the complete nameplate, connector and probe tip with the inquiry. Suggested internal-link anchor text is “Gefran PY2 25 mm Connector Position Transducer." Availability, condition and delivery require separate quotation confirmation.
