YUKEN DSG-01-3C60-A120-90 AC120V Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-01-3C60-A120-90 |
Product Details
Brand:
YUKEN
Model:
DSG-01-3C60-A120-90
Series:
DSG-01
Spool Function:
3C60
Valve Configuration:
4-Way, 3-Position
Coil Voltage:
AC 120V
Nominal Size:
NG06 / CETOP 03
Maximum Pressure:
Up To 31.5 MPa
Mounting Type:
Subplate Mounting
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 224.62 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DSG-01-3C60-A120-90 AC120V Directional Valve
The YUKEN DSG-01-3C60-A120-7090 is an AC120V solenoid-operated directional valve designed for industrial hydraulic flow-direction control.
This DSG-01 model uses a four-way, three-position 3C60 spool configuration and the NG06 / CETOP 03 subplate mounting standard.
Main Features
- AC120V solenoid operation
- Four-way, three-position configuration
- YUKEN 3C60 spool function
- Operating pressure up to 31.5 MPa
- NG06 / CETOP 03 mounting
- Suitable for industrial hydraulic control
Technical Specifications
| Brand | YUKEN |
| Model | DSG-01-3C60-A120-90 |
| Valve Type | Solenoid Operated Directional Valve |
| Spool Code | 3C60 |
| Configuration | 4-Way, 3-Position |
| Coil Voltage | AC 120V |
| Nominal Size | NG06 / CETOP 03 |
| Maximum Pressure | Up to 31.5 MPa |
| Mounting | Subplate Mounting |
| Design Number | 90 |
Typical Applications
- Hydraulic power units
- Industrial presses
- Machine tools
- Automated manufacturing equipment
- Material-handling machinery
Selection Notes
Check the complete model number, AC120V supply, 3C60 spool function, connector and 90 design number before ordering or replacing the valve.
