YUKEN DSG-03-2B2-A100-50 AC100V Solenoid Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-03-2B2-A100-50 |
YUKEN DSG-03-2B2-A100-50 AC100V Solenoid Directional Valve
The YUKEN DSG-03-2B2-A100-50 is a solenoid-operated directional valve designed for industrial hydraulic flow control.
This DSG-03 model features a four-way, two-position 2B2 spool configuration, an AC100V solenoid coil and an NG10 / CETOP 05 subplate mounting interface.
Main Features
- AC100V solenoid operation
- Four-way, two-position configuration
- YUKEN 2B2 spool function
- Pressure rating up to 31.5 MPa
- NG10 / CETOP 05 mounting interface
- Suitable for industrial hydraulic directional control
Technical Specifications
| Brand | YUKEN |
| Model | DSG-03-2B2-A100-50 |
| Valve Type | Solenoid Operated Directional Valve |
| Series | DSG-03 |
| Spool Function | 2B2 |
| Configuration | 4-Way, 2-Position |
| Coil Voltage | AC 100V |
| Pressure Rating | 31.5 MPa |
| Nominal Size | NG10 / CETOP 05 |
| Design Number | 50 |
Typical Applications
- Hydraulic power units
- Machine tools
- Industrial presses
- Production machinery
- Material-handling equipment
Selection Notes
Confirm the complete model code, AC100V power supply, 2B2 spool function, electrical connection and NG10 mounting interface before ordering. Two-position DSG-03 valves must not be replaced with three-position models without checking the hydraulic circuit.
Ordering Information
Please provide the complete model number, required quantity, destination country and a clear photograph of the original valve nameplate. Stock status, product condition, price and lead time are confirmed separately.
