YUKEN DSG-03-2B2-D24-50 Solenoid Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-03-2B2-D24-50 |
Product Details
Brand:
YUKEN
Model:
DSG-03-2B2-D24-50
Series:
DSG-03
Spool Function:
2B2
Valve Configuration:
4-Way, 2-Position
Coil Voltage:
DC 24V
Nominal Size:
NG10 / CETOP 05
Maximum Pressure:
Up To 31.5 MPa
Mounting Type:
Subplate Mounting
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 191.84 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DSG-03-2B2-D24-50 DC24V Solenoid Directional Valve
The YUKEN DSG-03-2B2-D24-50 is a DC24V solenoid-operated directional valve for controlling hydraulic oil direction in industrial machinery.
It combines a four-way, two-position 2B2 spool configuration with the larger NG10 / CETOP 05 subplate mounting interface.
Main Features
- DC24V solenoid operation
- Four-way, two-position configuration
- YUKEN 2B2 spool function
- Pressure rating up to 31.5 MPa
- NG10 / CETOP 05 mounting interface
- Suitable for automated hydraulic systems
Technical Specifications
| Brand | YUKEN |
| Model | DSG-03-2B2-D24-50 |
| Valve Type | Solenoid Operated Directional Valve |
| Series | DSG-03 |
| Spool Function | 2B2 |
| Configuration | 4-Way, 2-Position |
| Coil Voltage | DC 24V |
| Pressure Rating | 31.5 MPa |
| Nominal Size | NG10 / CETOP 05 |
| Design Number | 50 |
Typical Applications
- Hydraulic power units
- CNC machine tools
- Industrial automation equipment
- Hydraulic presses
- Material-handling machinery
Selection Notes
Verify the DC24V power supply, 2B2 spool function, connector type, NG10 mounting interface and complete design suffix against the original valve nameplate.
Ordering Information
Please provide the complete model number, quantity, destination and original nameplate photograph when requesting a quotation. Availability, condition and lead time are confirmed separately.
