YUKEN DSG-03-3C10-R220-50 Solenoid Directional Valve
| Place of Origin | Japan |
| Brand Name | YUKEN |
| Model Number | DSG-03-3C10-R220-50 |
Product Details
Valve Type:
Solenoid Operated Directional Valve
Model:
DSG-03-3C10-R220-50
Series:
DSG-03
Spool Function:
3C10
Valve Configuration:
4-Way, 3-Position
Coil Voltage:
AC 220V
Nominal Size:
NG10 / CETOP 05
Maximum Pressure:
Up To 31.5 MPa
Mounting Type:
Subplate Mounting
Payment & Shipping Terms
Minimum Order Quantity
1 unit
Price
USD 155.74 /Unit
Packaging Details
Brand new original packaging
Delivery Time
7-14 Days
Payment Terms
T/T
Supply Ability
10Units per Month
Product Description
YUKEN DSG-03-3C10-R220-50 AC220V Solenoid Directional Valve
The YUKEN DSG-03-3C10-R220-50 is an AC220V solenoid-operated directional valve from the YUKEN DSG-03 series.
This model combines a four-way, three-position 3C10 spool configuration with an NG10 / CETOP 05 subplate mounting interface.
Main Features
- AC220V solenoid operation
- Four-way, three-position configuration
- YUKEN 3C10 spool function
- Pressure rating up to 31.5 MPa
- NG10 / CETOP 05 mounting interface
- Suitable for industrial hydraulic circuits
Technical Specifications
| Brand | YUKEN |
| Model | DSG-03-3C10-R220-50 |
| Valve Type | Solenoid Operated Directional Valve |
| Series | DSG-03 |
| Spool Function | 3C10 |
| Configuration | 4-Way, 3-Position |
| Coil Voltage | AC 220V |
| Nominal Size | NG10 / CETOP 05 |
| Maximum Pressure | Up to 31.5 MPa |
| Design Number | 50 |
Typical Applications
- Hydraulic power units
- Machine tools
- Industrial presses
- Production machinery
- Material-handling systems
Selection Notes
Confirm the AC220V supply, exact 3C10 spool function, electrical connection and NG10 interface. Do not substitute another spool code without checking the hydraulic circuit.
Final specifications must be checked against the original valve nameplate and applicable manufacturer documentation.
