B&R 8V1022.00-2 ACOPOS 1kW Servo Drive 400-480V

Product Overview

The B&R 8V1022.00-2 is a modular ACOPOS servo drive for industrial single-axis motion applications. It accepts a three-phase 400 to 480 VAC supply and delivers 2.2 A continuous motor current with a peak current rating of 14 A. The nominal motor power rating is 1 kW.

The drive is designed for coordinated operation with the machine controller, installed encoder interface, communication module and configured motor. Its four plug-in module slots support application-specific feedback and network configurations, making the complete installed hardware arrangement an essential part of replacement selection.

Main Features

• ACOPOS modular servo-drive architecture
• Three-phase 400 to 480 VAC mains supply
• 2.2 A continuous current and 14 A peak current
• Nominal motor power rating of 1 kW
• Four slots for encoder, network and I/O modules
• Integrated line filter and braking resistor
• Integrated electronic restart inhibit
• Overload, short-circuit and ground-fault protection
• IP20 enclosure for protected cabinet installation

Technical Specifications

Interface and Encoder Configuration

The 8V1022.00-2 can be equipped with suitable ACOPOS plug-in modules for POWERLINK, CAN, EnDat, resolver, HIPERFACE, BiSS, SSI, incremental encoder or additional I/O functions. These modules are not identified by the base-drive number, so their individual part numbers must be checked on the installed drive.

Typical Applications

• Compact packaging machines
• Printing, labeling and converting equipment
• Automated handling and assembly stations
• Small conveyor and indexing axes
• Machine-tool auxiliary axes
• ACOPOS cabinet repair and drive replacement

Maintenance and Replacement Notes

The complete number 8V1022.00-2 must be checked rather than selecting a replacement only by the ACOPOS 1022 designation. Confirm the final revision, plug-in module arrangement, encoder system, network interface, motor data, braking configuration and controller project.

Before commissioning, restore or verify the appropriate machine parameters in Automation Studio. Current limits, feedback settings, communication configuration and safety-related functions must match the installed machine design.

Inquiry and Supply Notes

Please provide the complete nameplate, photographs of the installed plug-in modules, motor model and machine-controller details when requesting a quotation. Connector sets and removable interface modules should be confirmed as separate supply items.
