B&R 8BVI0028HWD0.000-1 ACOPOSmulti 3.8A Dual-Axis Inverter
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | 8BVI0028HWD0.000-1 |
Product Overview
The B&R 8BVI0028HWD0.000-1 is an ACOPOSmulti wall-mounted dual-axis inverter module. It contains two independently controlled motor outputs, each rated for 3.8 A continuous current, 9.5 A peak current and 2.8 kW continuous motor power.
The module connects to the ACOPOSmulti backplane and operates from a nominal 750 VDC bus. It provides a compact solution for machines that require two coordinated servo axes within a limited cabinet width.
Main Features
- Two independent inverter outputs
- 3.8 A continuous current per axis
- 9.5 A peak current per axis
- 2.8 kW continuous power per motor connection
- Nominal 750 VDC backplane supply
- Two slots for ACOPOSmulti plug-in modules
- Integrated motor-brake and temperature-monitoring connections
- Selectable 5, 10 and 20 kHz switching frequencies
- Wall-mounted IP20 construction
Technical Specifications
| Manufacturer | B&R Industrial Automation |
| Complete Model | 8BVI0028HWD0.000-1 |
| Product Family | ACOPOSmulti |
| Product Type | Dual-Axis Inverter Module |
| Motor Outputs | 2 |
| Continuous Current per Axis | 3.8 A |
| Peak Current per Axis | 9.5 A |
| Continuous Power per Axis | 2.8 kW |
| Nominal DC Bus Voltage | 750 VDC |
| DC Bus Capacitance | 165 µF |
| Switching Frequencies | 5 / 10 / 20 kHz |
| Plug-In Module Slots | 2 |
| Maximum Motor Cable Length | 25 m at 5 or 10 kHz |
| Protection Class | IP20 |
| Dimensions | 53 * 317 * 263 mm |
| Approximate Weight | 2.8 kg |
Compatible System and Applications
The module is used within ACOPOSmulti systems for synchronized positioning, speed and torque-control applications. Typical installations include packaging equipment, robotic handling, printing machinery, conveyor synchronization, feeders and assembly systems.
Maintenance and Replacement Notes
Confirm the full model 8BVI0028HWD0.000-1 and do not substitute it only by comparing the 3.8 A current rating. Verify the mounting method, number of axes, plug-in modules, motor feedback, holding-brake connections and ACOPOSmulti backplane configuration.
The mandatory terminal block set and removable interface modules should be checked separately. Record the original wiring and axis assignments before removing the installed inverter.
Related Models
Related wall-mounted dual-axis modules include 8BVI0014HWD0.000-1 and 8BVI0055HWD0.000-1. These models have different output capacities and require separate motor and project verification.
Inquiry and Supply Notes
Send the complete nameplate, backplane layout, connected motor models, feedback-module numbers, terminal photographs and controller project information for a reliable replacement check.
