B&R 8BVI0110HWS0.000-1 ACOPOSmulti 15.1A 11kW Inverter
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | 8BVI0110HWS0.000-1 |
Product Overview
The B&R 8BVI0110HWS0.000-1 is an ACOPOSmulti single-axis inverter module for industrial servo applications. It provides 15.1 A continuous motor current, 37.7 A peak current and 11 kW continuous motor power from the ACOPOSmulti DC-bus system.
The module uses a wall-mounted design and connects to a nominal 750 VDC ACOPOSmulti backplane. It includes two plug-in module positions and dedicated connections for the motor holding brake, motor temperature monitoring and enable signals.
Main Features
- Single-axis ACOPOSmulti inverter module
- 15.1 A continuous motor current
- 37.7 A peak motor current
- 11 kW continuous motor power
- Nominal 750 VDC bus connection
- Two slots for ACOPOSmulti plug-in modules
- Motor holding-brake and temperature-monitoring connections
- Selectable 5, 10 and 20 kHz switching frequencies
- Wall-mounted IP20 construction
Technical Specifications
| Manufacturer | B&R Industrial Automation |
| Complete Model | 8BVI0110HWS0.000-1 |
| Product Family | ACOPOSmulti |
| Product Type | Single-Axis Inverter Module |
| Motor Outputs | 1 |
| Continuous Output Current | 15.1 A |
| Peak Output Current | 37.7 A |
| Continuous Motor Power | 11 kW |
| Nominal DC Bus Voltage | 750 VDC |
| DC Bus Capacitance | 330 µF |
| Switching Frequencies | 5 / 10 / 20 kHz |
| Plug-In Module Slots | 2 |
| Maximum Motor Cable Length | 25 m at 5 or 10 kHz |
| Protection Class | IP20 |
| Dimensions | 53 * 317 * 263 mm |
| Approximate Weight | 2.9 kg |
Compatible System and Applications
The 8BVI0110HWS0.000-1 is intended for ACOPOSmulti systems with a compatible power-supply module, backplane, servo motor, feedback module and B&R controller. Typical applications include printing presses, packaging machines, plastics-processing equipment, synchronized conveyors, material handling and automated production axes.
Maintenance and Replacement Notes
Confirm the complete model 8BVI0110HWS0.000-1. The HWS0 configuration must not be confused with dual-axis HWD0 modules or SafeMOTION HWSS versions. These variants differ in axis count, interface arrangement and safety functionality.
The motor holding brake is intended for static holding. It must not be used as a normal dynamic operating brake or assumed to provide personnel-safety protection. Verify the motor brake data and machine safety design separately.
Record the backplane position, plug-in modules, motor feedback, holding-brake wiring, temperature-monitoring connection and controller parameters before removing the original module.
Related Models
Related single-axis ACOPOSmulti modules include 8BVI0220HWS0.000-1, 8BVI0330HWS0.000-1 and 8BVI0440HWS0.000-1. Current rating, physical width, wiring and project configuration vary between these models.
Inquiry and Supply Notes
For replacement checking, provide the complete nameplate, backplane arrangement, installed plug-in module numbers, motor model, encoder type, controller project and photographs of the terminal connections. The mandatory terminal block set should be confirmed separately.
