B&R 8BVI0014HWD0.000-1 ACOPOSmulti 1.9A Dual-Axis Inverter
| Place of Origin | Germany |
| Brand Name | B&R |
| Model Number | 8BVI0014HWD0.000-1 |
Product Overview
The B&R 8BVI0014HWD0.000-1 is a compact ACOPOSmulti dual-axis inverter module containing two independent motor inverter outputs. Each axis provides 1.9 A continuous current, 4.7 A peak current and up to 1.4 kW continuous motor power.
The module operates from the ACOPOSmulti backplane with a nominal 750 VDC bus. Its dual-axis design reduces cabinet width while retaining separate motor connections, brake control and temperature-monitoring functions for the two connected axes.
Main Features
- Two independent inverter outputs in one module
- 1.9 A continuous current per motor connection
- 4.7 A peak current per motor connection
- 1.4 kW continuous power per axis
- Nominal 750 VDC ACOPOSmulti bus connection
- Two ACOPOSmulti plug-in module slots
- Connections for motor holding brakes and temperature monitoring
- Wall-mounted compact construction
- Overload, short-circuit and ground-fault protection
Technical Specifications
| Manufacturer | B&R Industrial Automation |
| Complete Model | 8BVI0014HWD0.000-1 |
| Product Family | ACOPOSmulti |
| Product Type | Dual-Axis Inverter Module |
| Motor Outputs | 2 |
| Continuous Current per Axis | 1.9 A |
| Peak Current per Axis | 4.7 A |
| Continuous Power per Axis | 1.4 kW |
| Nominal DC Bus Voltage | 750 VDC |
| Switching Frequencies | 5 / 10 / 20 kHz |
| Plug-In Module Slots | 2 |
| Mounting Type | Wall mounting |
| Protection Class | IP20 |
| Dimensions | 53 * 317 * 263 mm |
| Approximate Weight | 2.8 kg |
Compatible System and Applications
This module is intended for ACOPOSmulti systems using a compatible backplane, power-supply module, controller, plug-in feedback modules and servo motors. Typical uses include compact packaging axes, feeders, labeling equipment, small handling systems and synchronized auxiliary axes.
Maintenance and Replacement Notes
Confirm the full model 8BVI0014HWD0.000-1, including the HWD0 and revision suffix. Similar ACOPOSmulti variants may use cold-plate mounting, pass-through mounting, different feedback arrangements or different safety functionality.
Record the motor and feedback connections for both axes before removing the original module. The terminal block set, plug-in modules and shield components should be verified separately because they may not be supplied with the base module.
Related Models
Related dual-axis wall-mounted modules include 8BVI0028HWD0.000-1 and 8BVI0055HWD0.000-1. These models have different current and power capacities and are not direct substitutes without engineering review.
Inquiry and Supply Notes
Provide the complete nameplate, photographs of both axis connections, installed plug-in modules, backplane configuration, motor models and controller project details for replacement verification.
