B&R 8BVI0220HWS0.000-1 ACOPOSmulti 22A Single-Axis Inverter

Product Overview

The B&R 8BVI0220HWS0.000-1 is a wall-mounted ACOPOSmulti single-axis inverter module for industrial servo applications requiring up to 22 Aeff continuous output current. It provides one motor connection, 16 kW continuous motor power and a peak current rating of 55 Aeff.

This model is intended for use as part of a complete ACOPOSmulti drive system. It receives power through the ACOPOSmulti DC bus and works with the applicable B&R controller, motor, feedback interface and machine software configuration.

Technical Specifications

Selection Notes

The HWS0 configuration identifies a single-axis wall-mounted inverter design. It should not be confused with the HWD0 dual-axis version, even when both modules carry the 0220 current designation. The number of motor outputs, terminal arrangement and application configuration are different.

Typical Applications

• High-performance packaging and converting machinery
• Printing and web-processing equipment
• Material-handling and positioning systems
• Production machines with coordinated servo axes
• Replacement of an existing same-code ACOPOSmulti inverter

Replacement Checklist

• Compare the complete 8BVI0220HWS0.000-1 material number.
• Verify single-axis rather than dual-axis hardware.
• Check motor current, feedback interface and holding-brake requirements.
• Confirm installed plug-in modules and functional-safety configuration.
• Verify controller firmware, Automation Studio project and drive parameters.
• Confirm terminal blocks, cable cross-sections and cabinet cooling.
