Yaskawa SGDH-10DE-OY Sigma-II 1kW 400V Three-Phase Servo Drive
| Place of Origin | USA |
| Brand Name | SGDH-10DE-OY |
| Model Number | SGDH-08AE-S-OY |
Product Overview
The Yaskawa SGDH-10DE-OY is a Sigma-II series 400 V class AC SERVOPACK designed for single-axis control of compatible servo motors with a maximum applicable capacity of 1.0 kW. It supports precision position, speed, and torque control for industrial automation and machine motion applications.
The -OY suffix identifies a system-specific Yaskawa/Omron configuration. Its complete suffix, controller project, interface arrangement, and hardware or firmware revision must be checked before replacement.
Main Features
- 1.0 kW maximum applicable servo motor capacity
- Three-phase 380–480 VAC main circuit input
- 3.5 A continuous rated output current
- Position, speed, and torque control modes
- Analog voltage and pulse train command support
- Sigma-II serial encoder feedback
- Automatic tuning and vibration suppression functions
- OY system-specific configuration
Technical Specifications
| Model | SGDH-10DE-OY |
| Series | Yaskawa Sigma-II |
| Product Type | AC Servo Drive / SERVOPACK |
| Main Circuit Input | Three-phase 380–480 VAC, 50/60 Hz |
| Applicable Motor Capacity | 1.0 kW |
| Continuous Output Current | 3.5 A |
| Maximum Output Current | 8.5 A |
| Control Modes | Position, speed, and torque |
| Command Interface | Analog voltage and pulse train; verify OY configuration |
| Encoder Feedback | Sigma-II serial encoder |
| Controlled Axes | One |
| Speed Frequency Response | 400 Hz |
Compatible System and Applications
The SGDH-10DE-OY is intended for selected Sigma-II 400 V motors, including compatible SGMGH-09D, SGMSH-10D, SGMUH-10D, SGMAH-07D, and SGMPH-08D configurations. Final compatibility depends on the complete motor suffix and installed machine system.
Typical applications include machine tools, packaging equipment, printing machinery, indexing systems, material handling equipment, production lines, and industrial positioning axes.
Maintenance and Replacement Notes
Back up the original drive parameters before removing the installed unit. Confirm the full SGDH-10DE-OY nameplate, hardware or firmware revision, controller project, installed interface module, communication network, motor model, encoder type, brake circuit, regenerative resistor, and cable set.
Do not automatically replace this model with SGDH-10DE. Verify connector assignments and OY system requirements first. After installation, test motor direction, electronic gearing, limit signals, brake operation, alarms, and tuning at reduced speed.
Related Models
Related models include SGDH-05DE-OY, SGDH-15DE-OY, SGDH-10DE, and SGDH-20DE-OY. Differences in rated capacity, complete suffix, firmware, connectors, and compatible motors must be checked before substitution.
Inquiry and Supply Notes
Please provide clear photographs of the complete nameplate and connectors together with the controller model, controller project, communication network, motor model, encoder type, brake requirement, cable part numbers, installed modules, and parameter backup. Product condition and included components should be confirmed individually.
