Yaskawa SGDV-R90A11A Sigma-V 100W MECHATROLINK-II Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-R90A11A |
Product Overview
The Yaskawa SGDV-R90A11A is a compact Sigma-V SERVOPACK designed for a compatible 100 W rotary servomotor. It communicates through the MECHATROLINK-II digital motion network and is intended for precise single-axis control within compatible Yaskawa controller systems.
Main Features
- Compatible motor capacity of 100 W.
- MECHATROLINK-II digital motion-network interface.
- Continuous output current of 0.91 A.
- Maximum output current of 2.9 A.
- Single-axis position, speed and torque control.
- Speed frequency response of up to 1.6 kHz.
- Integrated Safe Torque Off function.
Technical Specifications
| Manufacturer | Yaskawa Electric |
| Series | Sigma-V SGDV |
| Model | SGDV-R90A11A |
| Compatible Motor Capacity | 100 W |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Continuous Output Current | 0.91 A |
| Maximum Output Current | 2.9 A |
| Communication Interface | MECHATROLINK-II |
| Motor Type | Rotary Servomotor |
| Number of Axes | 1 |
| Encoder Feedback | Sigma-V Serial Encoder |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO |
Compatible System and Applications
This SERVOPACK is used in compatible MECHATROLINK-II systems with a suitable Sigma-V rotary servomotor. Typical applications include compact positioning axes, inspection equipment, electronic assembly machinery, semiconductor equipment, small feeders and synchronized automation systems.
Maintenance and Replacement Notes
Verify the complete model and suffix before replacement. The controller project must support MECHATROLINK-II, and the network address, communication cycle, firmware, parameter settings and termination arrangement must be checked.
Confirm the motor model, encoder specification, holding brake, network cable, power cable and encoder cable. The analog and pulse model SGDV-R90A01A uses a different command architecture and is not a direct interface-equivalent replacement.
Related Models
Related models include SGDV-R90A01A, SGDV-1R6A11A, SGDV-2R8A11A and other SGDV-R90A configurations. Interface codes and extended suffixes must be verified against the installed machine.
Inquiry and Supply Notes
Please provide the complete nameplate model, controller model, communication network, motor model, encoder information, firmware details and clear equipment photographs. Condition and included connectors or accessories must be confirmed in the individual quotation.
