Yaskawa SGDV-330A01A Sigma-V 5kW Analog Pulse Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-330A01A |
Product Overview
The Yaskawa SGDV-330A01A is a Sigma-V series single-axis SERVOPACK designed for a compatible 5.0 kW rotary servomotor. It uses analog voltage and pulse-train command inputs and provides high-current servo control for demanding positioning, speed-control and torque-control applications.
Main Features
- Designed for a compatible 5.0 kW Yaskawa Sigma-V rotary servomotor.
- Analog voltage and pulse-train command architecture.
- Continuous output current of 32.9 A.
- Maximum output current of 84 A.
- Speed frequency response of up to 1.6 kHz.
- Supports Sigma-V serial encoder feedback.
- Integrated Safe Torque Off function.
- Suitable for high-power industrial motion-control axes.
Technical Specifications
| Manufacturer | Yaskawa Electric |
| Series | Sigma-V SGDV |
| Model | SGDV-330A01A |
| Compatible Motor Capacity | 5.0 kW |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Continuous Output Current | 32.9 A |
| Maximum Output Current | 84 A |
| Control Interface | Analog Voltage and Pulse Train |
| Motor Type | Rotary Servomotor |
| Number of Axes | 1 |
| Encoder Feedback | Sigma-V Serial Encoder |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO |
Compatible System and Applications
The SGDV-330A01A is suitable for compatible Sigma-V rotary servo systems used in machine tools, large material-handling mechanisms, printing machinery, packaging equipment, forming machines and production equipment requiring precise control of high-inertia mechanical loads.
Maintenance and Replacement Notes
Before replacement, verify the complete SGDV-330A01A model and any extended suffix shown on the nameplate. Confirm the firmware version, parameter file, controller project, analog or pulse command configuration and machine safety circuit.
Check the motor model, encoder type, holding brake, regenerative resistor or regenerative unit, power-supply capacity, protective devices, contactor, cooling conditions and all power, encoder and control cables. Another SGDV interface version or an SGD7S drive must not be treated as directly interchangeable without engineering verification.
Related Models
Related models include SGDV-200A01A, SGDV-470A01A, SGDV-330A11A and other SGDV-330A configurations. Different interface codes and extended suffixes can identify important differences in communication, feedback or application hardware.
Inquiry and Supply Notes
Please provide the complete model suffix, nameplate photographs, motor model, controller model, command method, encoder information, brake configuration and existing cable details when requesting a quotation. Product condition and included connectors or accessories must be confirmed for each offer.
