Yaskawa SGDV-200A01A Sigma-V 3kW Analog Pulse Servo Drive 200V
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-200A01A |
Product Overview
The Yaskawa SGDV-200A01A is a Sigma-V series SERVOPACK designed for controlling a compatible 3.0 kW Yaskawa rotary servomotor. Its analog voltage and pulse-train command interface supports high-power positioning, speed-control and torque-control applications in industrial machinery.
Main Features
- Designed for a compatible 3.0 kW Sigma-V rotary servomotor.
- Analog voltage and pulse-train command interface.
- Rated output current of 19.6 A.
- Maximum output current of 56 A.
- High-performance single-axis motion control.
- Speed frequency response of up to 1.6 kHz.
- Integrated STO through the HWBB safety circuit.
Technical Specifications
| Manufacturer | Yaskawa Electric |
|---|---|
| Series | Sigma-V SGDV |
| Model | SGDV-200A01A |
| Compatible Motor Capacity | 3.0 kW |
| Main Circuit Input | Three-Phase 200–230 VAC |
| Control Circuit Input | Single-Phase 200–230 VAC |
| Rated Output Current | 19.6 A |
| Maximum Output Current | 56 A |
| Command Interface | Analog Voltage and Pulse Train |
| Motor Type | Rotary Servomotor |
| Number of Axes | 1 |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | STO via HWBB |
Compatible System and Applications
The SGDV-200A01A is intended for higher-power Sigma-V rotary servo systems. Typical applications include machine tools, forming equipment, material-handling systems, packaging machinery, printing equipment and industrial production lines requiring accurate control of larger mechanical loads.
Maintenance and Replacement Notes
Before replacing this SERVOPACK, verify the full model suffix, nameplate input and output ratings, firmware, parameter data, controller project and analog or pulse command configuration. The motor capacity alone is not sufficient to determine compatibility.
Confirm the motor model, encoder type, holding brake, regenerative resistor or regenerative unit requirements, power supply capacity, circuit protection, contactor, power cable, encoder cable and control wiring. Thermal installation and cabinet ventilation should also be checked for this higher-current model.
A different SGDV interface code or a newer SGD7S drive must not be treated as a direct replacement without reviewing controller compatibility, wiring changes, parameters and mechanical dimensions.
Related Models
Related Sigma-V models include SGDV-180A01A, SGDV-330A01A, SGDV-200A11A and other SGDV-200A configurations. Interface codes, revision letters and extended suffixes can identify significant hardware or application differences.
Inquiry and Supply Notes
Please provide the complete SERVOPACK model and suffix, motor nameplate, controller model, command method, encoder information, brake configuration and photographs of all existing connections. Product condition, included accessories and configuration must be confirmed for each quotation.
