Yaskawa SGDV-5R5A01A Sigma-V 750W 200V Analog Pulse Servo Drive
| Place of Origin | USA |
| Brand Name | YASKAWA |
| Model Number | SGDV-5R5A01A |
Product Overview
The Yaskawa SGDV-5R5A01A is a Sigma-V series 750 W AC SERVOPACK for single-axis control of compatible 200 V rotary servo motors. It accepts analog voltage and pulse train commands and supports position, speed, and torque control for industrial automation equipment.
Main Features
- 750 W maximum applicable servo motor capacity
- Three-phase 200–230 VAC main circuit input
- 5.5 A continuous rated output current
- Analog speed and torque command inputs
- Pulse train position command support
- 1.6 kHz speed frequency response
- Sigma-V high-resolution serial encoder interface
- Integrated Safe Torque Off through HWBB
- Automatic tuning and vibration suppression
Technical Specifications
| Model | SGDV-5R5A01A |
| Series | Yaskawa Sigma-V |
| Product Type | Single-Axis AC Servo Drive / SERVOPACK |
| Main Circuit Input | Three-phase 200–230 VAC, 50/60 Hz |
| Control Circuit Input | Single-phase 200–230 VAC, 50/60 Hz |
| Maximum Applicable Motor Capacity | 750 W |
| Continuous Output Current | 5.5 A |
| Maximum Output Current | 16.9 A |
| Control Interface | Analog voltage and pulse train |
| Supported Control Modes | Position, speed, and torque |
| Encoder Interface | Sigma-V serial encoder |
| Speed Frequency Response | 1.6 kHz |
| Safety Function | Integrated STO through HWBB |
Compatible System and Applications
The SGDV-5R5A01A is intended for selected 200 V Sigma-V rotary servo motors rated up to 750 W. Compatible configurations may include appropriately rated SGMAV, SGMJV, SGMEV, SGMAH, SGMPH, and other approved motor families. Compatibility must be confirmed from the Yaskawa motor-drive combination table.
Typical applications include packaging systems, automated assembly lines, material handling equipment, printing machinery, pick-and-place mechanisms, feeders, indexing equipment, and precision machine axes.
Maintenance and Replacement Notes
Save the original parameters before removing the installed drive. Confirm the full SGDV-5R5A01A model, nameplate, firmware, hardware revision, controller project, command signals, electronic gearing, motor model, encoder format, brake option, regenerative circuit, and cable set.
SGDV-5R5A11A and SGDV-5R5A21A use different communication interfaces. SGDV-5R5A01A002000 and other extended-suffix models may also contain hardware or environmental options and should not be treated as identical without verification.
Related Models
Related models include SGDV-5R5A01A002000, SGDV-5R5A11A, SGDV-5R5A21A, SGDV-3R8A01A, and SGDV-7R6A01A. Compare the complete suffix, rated current, command interface, firmware, and motor requirements.
Inquiry and Supply Notes
Please provide the complete model and nameplate photographs, controller model, controller project, firmware revision, command interface, motor model, encoder type, brake configuration, regenerative resistor, cable part numbers, and original parameter backup. Product condition and included components should be confirmed separately.
